ABB HIEE320605R1 Power Module

Product Overview:
The ABB HIEE320605R1 Power Module is a key component of ABB control systems, providing stable and reliable DC power. The module features high-efficiency energy conversion, wide input voltage range, overload protection, overvoltage/overcurrent protection, and short-circuit protection, ensuring long-term safe and stable operation of the automation system.

Technical Specifications:

• Model: HIEE320605R1

• Type: Power Module

• Input Voltage Range: 100–240 V AC, 50/60 Hz

• Output Voltage: 24 V DC

• Output Current: Up to 10 A (typical)

• Power Rating: Up to 240 W

• Efficiency: ≥ 92%

• Overload Protection: Auto-recovery

• Overvoltage/Overcurrent/Short-Circuit Protection: Built-in

• Operating Temperature: -20°C to +60°C

• Storage Temperature: -40°C to +70°C

• Relative Humidity: 5% to 95% RH (non-condensing)

• Protection Class: IP20

• Mounting: DIN rail or rack-mounted

• Certifications: CE, UL, RoHS

Key Features and Advantages:

1. Stable and Reliable Power Output – Ensures continuous operation of control system modules.

2. Comprehensive Safety Protection – Overload, overvoltage, overcurrent, and short-circuit protection enhance system safety.

3. High Energy Efficiency – ≥ 92% efficiency reduces energy consumption.

4. Wide Input Voltage Range – Adaptable to various power grid conditions.

5. Industrial-Grade Design – Operates reliably in high temperature, humidity, and vibration environments.

6. Modular Installation – DIN rail or rack-mounted for easy maintenance and replacement.

Applications:

• Distributed Control Systems (DCS)

• Factory automation production lines

• Power automation and energy management systems

• Process industries: chemical, metallurgy, cement, paper

• Water treatment and environmental monitoring

• Building automation and smart control systems

Precautions:

1. Always disconnect power before installation or removal.

2. Ensure proper grounding to prevent EMI and ESD damage.

3. Correctly connect output terminals to avoid overload.

4. Avoid high humidity, dust, or corrosive environments.

5. Regularly inspect ventilation and heat sinks to ensure proper cooling.

6. Do not disassemble or modify the module.
