ABB HIEE300885R0102 Inverter Module

Product Overview:
The ABB HIEE300885R0102 is a high-performance Inverter Module designed for ABB automation and drive systems. It is used for motor control, energy conversion, and precision speed regulation. Featuring advanced IGBT technology and vector control algorithms, it delivers high efficiency and stable performance across industrial and energy applications.

Technical Specifications:

• Model: HIEE300885R0102

• Type: Inverter Module

• Input Voltage: 24V DC / 48V DC / 110V DC (depending on system configuration)

• Output Voltage: 0 – 480V AC

• Output Current: 10A – 40A (depending on model)

• Output Frequency Range: 0 – 400 Hz

• Control Method: PWM modulation / Vector control

• Efficiency: ≥96%

• Overload Capacity: 150% of rated current for 60 seconds

• Communication Ports: Ethernet, RS-485, Modbus RTU/TCP, Profibus (optional)

• Cooling Method: Forced air / Natural convection

• Operating Temperature: -10°C to +55°C

• Storage Temperature: -40°C to +70°C

• Protection Class: IP20 / IP40 (depending on installation)

• Mounting Type: DIN rail or panel mount

• Certifications: IEC 61800, CE, UL, RoHS

Key Features and Advantages:

1. High-Performance Motor Control – Advanced vector control for precise torque and speed regulation.

2. High Efficiency – Up to 96% energy conversion efficiency, reducing system losses.

3. Modular Design – Easy integration, maintenance, and scalability.

4. Robust Protection – Comprehensive protection against overload, short circuit, and over-temperature.

5. Flexible Communication – Supports multiple industrial protocols for seamless connectivity.

6. Low Noise Operation – Optimized PWM technology minimizes EMI and motor noise.

Applications:

• Industrial automation and process control

• Power and energy management systems

• Pumps, fans, and compressors

• Conveying and packaging machinery

• Building automation and HVAC systems

• Renewable energy applications (e.g., solar inverter systems)

Precautions:

1. Verify input voltage and load compatibility before installation.

2. Ensure proper grounding to avoid EMI and static damage.

3. Do not plug or unplug modules under power.

4. Maintain adequate ventilation to prevent overheating.

5. Clean cooling fans and heat sinks regularly.

6. Follow installation and parameter setup instructions in the product manual.
