ABB HIEE300690R1 relay output module

ABB HIEE300690R1 Relay Output Module – Product Information

1. Product Overview

The ABB HIEE300690R1 is a high-performance relay output module designed for industrial automation and power control systems.
It provides reliable multi-channel signal output via electromechanical relays, capable of driving motors, lights, alarms, and other load devices. HIEE300690R1 is compatible with ABB control systems and suitable for a wide range of automation applications, ensuring stable and reliable system operation.

2. Technical Specifications

• Model: HIEE300690R1

• Type: Relay Output Module

• Relay Channels: 8

• Rated Output Current: Max 5 A

• Output Voltage: 250 V AC / 30 V DC

• Operating Voltage: 24 V DC

• Switch Type: Electromechanical Relay

• Power Consumption: Approx. 3 W

• Operating Temperature: -20 ℃ to +60 ℃

• Storage Temperature: -30 ℃ to +80 ℃

• Mounting Method: DIN Rail

• Dimensions: 120 × 90 × 40 mm

• Weight: Approx. 1.0 kg

• Protection Class: IP20

• Certifications: CE, RoHS

3. Features and Advantages

1. Multi-Channel Output – 8 relay channels for flexible multi-load control.

2. High Reliability – Industrial-grade relays with strong durability and interference resistance.

3. Modular Design – DIN rail mounting for easy integration and maintenance.

4. Strong Compatibility – Compatible with ABB and third-party control systems.

5. Safety Protection – Includes overload protection to ensure device and system safety.

6. Low Power Design – Energy-efficient for long-term continuous operation.

4. Application Areas

• Industrial automation systems

• Motor control and drive systems

• Alarm and signal indication systems

• Inverter and excitation control systems

• Energy management and distribution systems

5. Precautions

1. Ensure the module is compatible with the system and load devices before installation.

2. Provide a stable power supply to avoid affecting relay performance.

3. Avoid using in high humidity, corrosive, or strong electromagnetic interference environments.

4. Regularly check relay contact status and wiring connections to ensure normal operation.

5. Installation and maintenance must be performed by trained professionals; do not disassemble or modify the module.

The structure and details of the product：
