ABB HIEE 305111R0001 Power Control Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB HIEE 305111R0001 is a Power Control Module designed for high-performance industrial automation systems. It provides precise control of motors, drives, or other high-power equipment, offering reliable power switching, overload protection, and status monitoring. Widely used in power distribution, automated production lines, and motor control systems.

2. Technical Specifications

• Model: HIEE 305111R0001

• Type: Power Control Module

• Rated Operational Voltage: AC 400–690 V

• Rated Current: Customizable per load, supports high-current output

• Control Interface: Compatible with digital and analog I/O

• Output Type: Controllable power output, suitable for three-phase load control

• Protection Features: Overcurrent, overvoltage, short-circuit protection, status monitoring

• Response Time: ≤ 10 ms

• Operating Temperature: ‑20 °C to +60 °C

• Storage Temperature: ‑40 °C to +85 °C

• Mounting: DIN rail or base mounting

• Protection Rating: IP20

• Dimensions (H×W×D): 160 × 75 × 120 mm

• Standards: IEC/EN 60947, IEC/EN 61439

3. Key Advantages & Features

1. High-Performance Power Control – Precise control of motors and industrial equipment.

2. Multiple Protection Functions – Built-in overcurrent, overvoltage, short-circuit, and status monitoring.

3. Fast Response – ≤ 10 ms suitable for dynamic control.

4. Interface Compatibility – Supports digital and analog I/O for integration with PLCs and controllers.

5. Modular Design – DIN rail or base mounting for easy integration and maintenance.

6. Industrial Environment Adaptability – Wide operating temperature range for various conditions.

4. Typical Applications

• Industrial automation control systems

• Motor drives and power management

• Power distribution and energy management

• Automated production lines and machinery control

• HVAC systems and high-power load control

5. Installation & Usage Notes

1. Voltage and Current Matching – Ensure module ratings match the connected load.

2. Proper Wiring – Connect input and output terminals per wiring diagram.

3. Environmental Conditions – Avoid high humidity, dust, or corrosive environments.

4. Regular Inspection – Check module connections, indicators, and load conditions periodically.

5. Secure Installation – Ensure module is mounted firmly to prevent vibration affecting performance.
