ABB FT1-014 129A514G01 Test Switch

Product Information: ABB FT1-014 129A514G01 Test Switch

Detailed Specifications:

• Model: FT1-014 129A514G01

• Type: Test Switch

• Rated Voltage: 690 V AC / 440 V DC

• Rated Current: 16 A

• Contact Type: Normally Open (NO) contact

• Rated Power: 4 kW (AC); 1.5 kW (DC)

• Frequency Range: 50/60 Hz

• Wiring Type: Screw terminal connection

• Material: Reinforced plastic housing, high temperature resistant, fire-resistant

• Ingress Protection: IP20 (dustproof)

• Operating Temperature Range: -20°C to +55°C

• Storage Temperature: -40°C to +85°C

• Dimensions: 120 x 120 x 60 mm

• Weight: 0.3 kg

• Certifications: CE, UL, IEC 60947-3, ISO 9001

Product Advantages and Features:

1. High Reliability: The ABB FT1-014 129A514G01 test switch is built with high-quality materials and precision manufacturing, ensuring long-term stable performance, making it ideal for various industrial automation control systems.

2. High Current Carrying Capacity: With a current rating of up to 16 A, it can safely and efficiently control high-power loads, suitable for testing and commissioning of electrical equipment and systems.

3. Flexible Wiring Method: The screw terminal connection makes wiring easy and ensures stable electrical contact, suitable for different types of electrical systems.

4. Safety Design: The reinforced plastic housing provides high temperature resistance, fire resistance, and dust protection, making it ideal for various industrial environments, ensuring safety during use.

5. Ease of Operation: The normally open contact design allows for easy operation of the switch, reducing operation time and complexity, improving work efficiency.

6. Standard Certifications: Complies with international standards such as CE, UL, and IEC 60947-3, ensuring product quality and safety, suitable for use globally.

7. Compact Design: The compact size and lightweight design make it suitable for space-constrained equipment or systems, facilitating installation and maintenance.

Applications:

• Electrical Equipment Testing: Widely used in the testing and commissioning of electrical equipment to ensure performance checks before equipment operation.

• Industrial Automation Systems: Used in industrial control systems for electrical testing, ensuring the stability and reliability of control circuits.

• Power Distribution Systems: Used in electrical distribution equipment and systems for testing and maintenance of switchgear to ensure safe system operation.

• Control Panels and Distribution Cabinets: Provides convenient switch testing functionality in distribution cabinets, control panels, and other electrical equipment.

• Electrical Installation and Maintenance: Used for system testing and troubleshooting during electrical installation and maintenance to ensure smooth system operation.

Precautions:

1. Proper Installation: Ensure that the wiring is secure and complies with electrical safety standards during installation to avoid faulty connections.

2. Regular Inspection: Periodically check the working status of the test switch, particularly the wear of contacts, to ensure normal operation.

3. Environmental Suitability: Avoid exposure to high temperatures, humidity, or corrosive gases to maintain long-term performance.

4. Avoid Overload Use: Ensure the load current does not exceed the rated current value to prevent damage to the switch.

5. Protection Requirements: Ensure that the installation environment meets safety requirements, especially when used in high-voltage or high-power applications.

.
