ABB FS450R17KE3+AGDR-61C 64783831 IGBT module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Overview

The ABB FS450R17KE3+AGDR-61C IGBT Module (Part No. 64783831) is a high-performance power semiconductor module combining the FS450R17KE3 IGBT power unit with the AGDR-61C gate driver control. It is designed for industrial automation, high-power inverters, and motor drive systems, providing efficient energy conversion and precise switching for medium to high power applications while ensuring reliability and stability.

2. Technical Specifications

Additional electrical performance:

• Conduction loss: ~220 W

• Turn-on switching loss: ~120 μJ

• Turn-off switching loss: ~150 μJ

• Reverse recovery loss: ~40 μJ

• Leakage current: ~10 mA

3. Advantages and Features

1. High Voltage and Current Handling – Suitable for 1700 V and 450 A medium-to-high power applications.

2. Efficient Switching Performance – Supports high-speed switching up to 20 kHz for fast and precise control.

3. Wide Operating Temperature – From -25 to +155°C, suitable for various industrial environments.

4. Strong Short-Circuit Endurance – Up to 10 kA short-circuit withstand capability for enhanced system safety.

5. Modular Industrial Package – TO-247 module simplifies installation and thermal management.

6. Integrated Driver Control – AGDR-61C provides gate drive and protection for optimized module performance.

4. Applications

• Medium-to-high power inverters and converters

• Industrial motor drives and servo systems

• Renewable energy inverter systems (wind, solar)

• Industrial automation production lines and heavy-duty drives

• Electric transportation (rail, EV) drive control units

• High-efficiency energy conversion and power electronics systems

5. Installation and Maintenance Notes

1. Thermal Management – Ensure adequate heatsinks and airflow for cooling.

2. ESD Protection – Use anti-static measures during handling and installation.

3. Correct Wiring – Follow design manuals for power, control, and grounding connections.

4. Avoid Overload Operation – Do not exceed rated current, voltage, or frequency.

5. Regular Inspection and Maintenance – Check module, cooling system, and connections, and keep them clean.

6. Professional Installation and Commissioning – Recommended to be handled by experienced power electronics engineers.
