ABB FS200R12PT4 inverter driver board

• Product Overview

  The ABB ZGAD-561/FS200R12PT4 is a high-performance inverter driver board, widely used in ABB ACS880 series drives.
  This driver board integrates the Infineon FS200R12PT4 IGBT module and is designed for industrial automation systems, providing high efficiency and reliable performance.

  ---

  Key Technical Specifications

  • Model: ZGAD-561/FS200R12PT4

  • IGBT Module: FS200R12PT4

  • Rated Current: 200 A

  • Rated Voltage: 1200 V

  • Switching Frequency: up to 20 kHz

  • Insulation Voltage: 2500 V AC (1 min)

  • Operating Temperature Range: -40°C to +150°C

  • Cooling Method: air-cooled or liquid-cooled

  • Dimensions: approximately 130 × 70.6 × 20.55 mm

  • Weight: approximately 390 g

  ---

  Applications

  The ZGAD-561/FS200R12PT4 driver board is widely used in the following ABB drive series:

  • ACS880: general-purpose drive for various industrial applications

  • ACS580: compact drive for standard applications

  • ACS200: compact drive for simple applications

  Additionally, this driver board can be used in other industrial automation systems that require high power density and high reliability.

  ---

  Installation and Maintenance Recommendations

  • Installation Environment: Ensure the installation environment is dry and well-ventilated; avoid high temperature and humidity.

  • Electrical Connections: Connect power and load according to the product manual, ensuring secure and reliable wiring.

  • Cooling System: Regularly check the cooling system to ensure heat sinks and fans are functioning properly.

  • Routine Inspection: Periodically inspect the driver board operation to detect and resolve potential issues promptly.
