ABB FPR3311101R1022 Binary Output Unit

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB FPR3311101R1022 Binary Output Unit is a remote output module designed for the ABB Procontic CS31 automation system. The module, internally known as ICSO08Y1, provides digital output functionality used to drive actuators or signalling devices based on control logic. It supports eight electrically isolated transistor outputs and operates with a 24 V DC supply, making it suitable for industrial automation and control applications.hi.mooreplc.com

2. Technical Specifications

• Model: FPR3311101R1022

• Product Type: Binary Output Unit

• Series: ABB Procontic CS31

• Internal Model: ICSO08Y1

• Supply Voltage: 24 V DC

• Output Channels: 8 digital outputs

• Output Type: Electrically isolated transistor outputs

• Rated Output Voltage: 24 V DC

• Max Load per Channel: 2 A

• Total Max Load: approx. 8 A

• Min Load: ~50 mA

• Power Consumption (no load): ~0.2 A

• Power Dissipation: ~6 W

• Mounting Method: DIN rail or panel mount

• Operating Temperature: ‑20 ℃ to +50 ℃

• Connection Type: Screw terminals or plug‑in connectors

• Housing Material: Industrial‑grade plastic/metal

• Weight: approx. 0.32 kg

• Protection Rating: IP20 (typical)

• System Integration: Compatible with Procontic CS31 controllers and I/O unitshi.mooreplc.com

3. Advantages and Features

1. Multiple Digital Outputs
   Provides eight isolated outputs for simultaneous control of multiple devices.

2. Electrical Isolation
   Each channel is isolated, improving noise immunity and field reliability.

3. Strong Compatibility
   Seamlessly integrates with ABB Procontic CS31 series controllers and other I/O modules.

4. Compact Industrial Design
   Rugged enclosure suitable for industrial environments and compact installations.

5. Flexible Installation
   Designed for DIN rail or panel mounting to adapt to various field setups.

6. Modular Maintenance
   Modular construction simplifies servicing and replacement.hi.mooreplc.com

4. Typical Applications

• Output control in industrial automation systems

• Driving digital signals to field devices from PLCs

• Production line switch and indicator control

• Logic control and output interfacing in distribution systems

• Remote I/O expansion for process automation

• OEM automation systems module interfacesPL+Swiss

5. Installation and Usage Notes

1. Verify supply voltage and control logic compatibility before installation.

2. Always power off before wiring to avoid damage to the module or controller.

3. Avoid prolonged use in high humidity, high temperature, or areas with strong EMI.

4. Securely mount the module to a DIN rail or panel to prevent vibration damage.
