ABB FMBT-21 Drive Fieldbus Connection

Product Overview

The ABB FMBT-21 is a fieldbus communication module designed for ABB drives, enabling seamless integration with industrial automation systems via PROFIBUS DP protocol. It serves as a critical interface between ABB variable frequency drives (VFDs) and higher-level control systems, facilitating real-time data exchange and control commands .

Key Features

1. PROFIBUS DP Support

   • Complies with PROFIBUS DP-V1 standard, supporting baud rates up to 12 Mbps .

   • Enables cyclic data exchange for control (e.g., speed, torque) and diagnostic monitoring (e.g., faults, motor temperature) .

2. Plug-and-Play Integration

   • Hot-swappable design for easy installation and maintenance without system shutdown .

   • Compatible with ABB drives like ACS800, ACQ800, and DCS800 series .

3. Diagnostics and Status Indicators

   • LED indicators for power, communication status, and faults .

   • Supports DP-V1 diagnostics for detailed error reporting (e.g., cable breaks, station failures) .

4. Industrial Robustness

   • Operating temperature range: -25°C to +70°C .

   • IP20 protection for control cabinet installation .

Technical Specifications

Installation and Wiring

1. Mounting

   • Install the module on the drive’s option slot (refer to drive manual for exact location) .

2. PROFIBUS Wiring

   • Use shielded twisted-pair cables (e.g., PROFIBUS PA/DP type A).

   • Terminate both ends of the bus with 110Ω resistors .

3. Address Configuration

   • Set the PROFIBUS station address via DIP switches (range: 1–126) .

Configuration Steps

1. Drive Parameters

   • Enable fieldbus control: Set drive parameter 98.02 to "FIELDBUS" .

   • Map process data (e.g., speed reference, torque limit) via drive parameter group 51 .

2. PLC/PROFIBUS Master Setup

   • Install the GSDML file for FMBT-21 in the PLC engineering tool (e.g., Siemens STEP 7) .

   • Configure input/output addresses for data exchange (typically 4–8 bytes) .

Troubleshooting

• No Communication: Verify baud rate and station address match the master configuration .

• Intermittent Signals: Check cable shielding and grounding .

• Fault Codes: Refer to drive manual for PROFIBUS-specific errors (e.g., "E10027: Communication loss") .

Applications

• Industrial Automation: Conveyors, pumps, and fans in manufacturing plants .

• Process Control: Integration with DCS systems in chemical/petrochemical industries .

• Energy Management: Motor control in HVAC and water treatment systems .
