ABB FEA112-20 tension control module

ABB FEA112-20 Tension Control Module Product Data

Product Overview:

The ABB FEA112-20 is a high-performance tension control module designed for tension control applications in industrial automation systems. It uses advanced control algorithms to precisely adjust and control the tension in systems such as production lines, winding equipment, and conveyors. This module is widely used in industries such as textiles, pulp and paper, metal coils, and plastic films, helping to improve production efficiency, reduce material waste, ensure product quality, and enable automation.

The FEA112-20 module provides real-time tension monitoring, closed-loop control functionality, and various I/O interfaces, allowing seamless integration with other automation system devices to meet different control requirements. With efficient tension regulation and feedback mechanisms, it helps stabilize the production line, reduce tension fluctuations, and enhance safety.

Key Technical Specifications:

• Model: FEA112-20

• Power Supply: AC 110V - 240V, 50/60 Hz

• Operating Temperature Range: 0°C to +50°C

• Storage Temperature Range: -20°C to +70°C

• Output Signals: 4-20mA analog output, digital output

• Control Mode: Closed-loop tension control

• Input Signals: Tension sensor signal, speed sensor signal

• Communication Protocols: Modbus RTU, Profibus, Ethernet/IP, etc.

• Response Time: < 50 milliseconds

• Protection Rating: IP20

• Dimensions: Approx. 200mm x 160mm x 120mm

• Weight: Approx. 1.2 kg (may vary depending on configuration)

• Certifications: CE, UL, CSA, etc.

Product Advantages and Features:

1. High-Precision Tension Control: The FEA112-20 utilizes advanced closed-loop control algorithms to continuously adjust and maintain the required tension levels, effectively reducing tension fluctuations and improving product quality.

2. Multiple I/O Interfaces: It supports various input signals, including tension and speed sensors, and offers both analog and digital outputs for flexible integration with other equipment and systems.

3. Fast Response: The module has a response time of less than 50 milliseconds, ensuring real-time tension adjustments and preventing issues like excessive or insufficient tension.

4. Protocol Support: The FEA112-20 supports multiple industrial communication protocols such as Modbus RTU, Profibus, and Ethernet/IP, enabling seamless integration with different automation control systems for remote monitoring and control.

5. High Stability and Reliability: With a robust design and high-quality electronic components, the FEA112-20 provides reliable and stable operation in challenging industrial environments.

6. Automation and Intelligence: The module automatically adjusts tension levels and provides intelligent feedback mechanisms, helping enterprises achieve process automation and reduce manual intervention, improving production efficiency.

7. Modular Design: Its modular design makes installation, maintenance, and upgrades simple, providing flexibility to adapt to different production needs and environments.

8. Compact and Energy-Efficient: The module has a compact size and low power consumption, making it suitable for space-constrained environments while maintaining high performance.

Application Areas:

1. Textile Industry: The FEA112-20 is used to precisely control tension in textile machines, ensuring uniform fabric quality and production efficiency.

2. Pulp and Paper Production: It helps regulate tension in paper manufacturing lines, ensuring paper consistency and preventing breakage or wrinkles.

3. Metal Coiling: In metal rolling and coiling processes, the module prevents deformation or breakage of metal strips, ensuring high-quality metal coils.

4. Plastic Film: The module maintains stable tension in plastic film production, reducing film deformation, breakage, and dimensional variations.

5. Packaging Industry: In packaging production lines, the FEA112-20 controls the tension of packaging materials, ensuring material flatness and reliability.

6. Printing Industry: The module stabilizes tension during printing, ensuring high print quality and continuous production.

7. Automation Production Lines: It is used to control tension in material conveyance, winding, and stretching in automated production lines, optimizing the process.

Notes:

1. Sensor Calibration and Maintenance: The accuracy of tension sensors directly affects control performance. It is recommended to regularly check and calibrate the sensors to maintain accuracy.

2. Power Supply Stability: Ensure that a stable AC 110V-240V power supply is provided to prevent voltage fluctuations from affecting module performance.

3. Installation Location: Install the module in an appropriate location, avoiding vibration, humidity, and dust to ensure long-term stable operation.

4. Communication Configuration: Properly configure communication protocols and interfaces to ensure seamless connection and data exchange with other automation system devices.

5. Regular Inspection and Maintenance: Periodically inspect the module's operating status, clean terminal blocks and sensor interfaces, and maintain long-term stability.

6. Environmental Adaptability: The module is suitable for use in environments with temperatures ranging from 0°C to 50°C. Avoid extreme temperatures to maintain proper functionality.
