ABB EHDB360 contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB EHDB360 Contactor is a high-performance electrical switch used in ABB industrial electrical control systems to make or break AC circuits.
It is suitable for controlling motors, heaters, and other industrial loads, providing remote control, overload protection, and reliable frequent operation. Widely used in industrial automation, motor control, and electrical distribution systems.

Technical Specifications

Model: EHDB360
Module Type: AC Contactor
Rated Voltage: AC 690 V
Rated Operational Current: 360 A (AC-3 load)
Control Coil Voltage: 24–600 V AC/DC selectable
Contact Configuration: 3 NO + 1 NC (optional)
Mechanical Life: ≥10,000,000 operations
Electrical Life: ≥1,000,000 operations
Operation: Electromagnetic
Insulation Class: F
Protection Rating: IP20
Mounting: DIN rail or bolt mounting
Operating Temperature: -25°C to +55°C
Storage Temperature: -40°C to +70°C
Dimensions: approx. 300 × 150 × 180 mm
Weight: approx. 8.5 kg
Certifications: CE / UL / IEC60947-4-1

Features & Advantages

1. High Current Control – Supports AC motor loads up to 360 A.

2. Durable and Reliable – Meets industrial standards for mechanical and electrical life.

3. Wide Control Voltage Range – Coil selectable from 24–600 V AC/DC for versatile control.

4. Multiple Contacts – 3 NO + 1 NC contacts for diverse control and signaling applications.

5. Safety Protection – IP20 protection rating ensures safe operation.

6. Easy Installation – DIN rail or bolt mounting, convenient for maintenance and replacement.

Applications

• Industrial automation production lines

• Motor starting and control

• Heaters and process control equipment

• Electrical distribution systems

• Automated machinery

• Industrial process control

Precautions

1. Disconnect power before installation to ensure safety.

2. Select the contactor according to rated voltage and current to prevent overload.

3. Keep the environment dry and clean, avoid dust and corrosive gases.

4. Regularly inspect contact wear and coil status.

5. Use genuine ABB contactors to ensure reliability and compatibility.

The structure and details of the product：
