ABB EH450C-1 DC contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB EH450C-1 DC Contactor is a high-performance DC electrical contactor used in ABB industrial control systems for switching and protecting DC circuits.
It provides fast and reliable switching under high current and frequent operation, suitable for power electronics, motor drives, battery-powered systems, and industrial automation DC control.

2. Main Technical Specifications (Typical)

• Model: EH450C-1

• Product Type: DC Contactor

• Rated Voltage: DC 24V / 48V / 110V / 220V (depending on system configuration)

• Rated Current: 450 A

• Poles: 1 pole or multiple poles (depending on configuration)

• Mechanical Life: > 500,000 operations

• Electrical Life: > 50,000 operations (depending on load)

• Insulation Rating: ≥ 2.5 kV

• Operating Time: Typically 30–50 ms

• Mounting: Screw fixed or DIN rail installation

• Operating Temperature Range: -25 ℃ to +55 ℃

3. Key Advantages and Features

1. High Current Capacity

   • Supports up to 450 A DC load

   • Suitable for heavy-duty industrial equipment

2. High Reliability and Durability

   • Long electrical and mechanical life

   • Supports frequent operation

3. Fast Switching Performance

   • Short operating time ensures rapid circuit make/break

   • Suitable for high-dynamic industrial control

4. Modular Mounting Design

   • Screw or DIN rail installation

   • Easy system integration and maintenance

5. Industrial-Grade Safety

   • High insulation rating

   • Provides overcurrent and short-circuit protection

4. Typical Applications

• ABB industrial DC drive systems

• Battery-powered systems and UPS

• Electric vehicles, railway traction, and electric transport

• DC switching in power electronics

• Industrial automation DC control

• Motor drives and high-power DC load control

5. Installation and Maintenance Notes

1. Verify Rated Voltage and Current

   • Ensure the contactor ratings match the system load

2. Power-Off Before Installation

   • Disconnect DC power before installing or removing the contactor

3. Proper Wiring

   • Secure connections for power and control lines

   • Avoid parallel routing of high-current and signal wires

4. Environmental Conditions

   • Avoid high temperature, humidity, and corrosive environments

   • Ensure proper ventilation

5. Protection and Inspection

   • Regularly check mechanical operation and electrical contacts

   • Ensure long-term stable operation
