ABB E16DU-18.9 1SAX111001R1105 Electronic Overload Relay

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB E16DU-18.9 Electronic Overload Relay is an electronic device designed to provide precise overload protection for AC motors. It continuously monitors motor current and quickly disconnects the circuit in cases of overload, locked-rotor, or phase loss, protecting the motor and control system.

The relay works with ABB contactors, features adjustable overload settings, fast response, and supports remote monitoring and status indication. The E16DU series complies with IEC 60947-4-1 standards, making it suitable for industrial automation, machinery, and motor control systems.

2. Technical Specifications

3. Key Features & Advantages

• Precise protection: Electronic current monitoring with fast response to overload, locked-rotor, or phase loss

• Multi-function protection: Supports overload, locked-rotor, underload, and phase-failure protection

• Adjustable current: Set protection range according to motor rated current

• Easy installation: Can be mounted with ABB contactors or on DIN rail

• Clear status indication: LED displays operational and fault status

• Remote monitoring support: Optional communication interfaces for industrial automation

• Long service life: No mechanical contact wear, high reliability

4. Typical Applications

• AC motor protection in industrial environments

• Motor control in production lines and automation equipment

• Pumps, fans, compressors, and conveyor systems

• CNC machines and precision machinery

• HVAC and building motor control systems

• Chemical, pharmaceutical, food processing, mining, and metallurgical industries

5. Installation & Safety Notes

1. Ensure the relay rated current matches the motor rated current to avoid nuisance trips or insufficient protection.

2. Mount securely with ABB contactor or on DIN rail.

3. Avoid high temperature, high humidity, or corrosive environments; ensure proper ventilation.

4. Set overload protection current and time delay according to motor characteristics.

5. Regularly check status indicators, output contacts, and wiring terminals.

6. Avoid strong electromagnetic interference near the relay.

7. Ensure wiring is secure to prevent loose connections or poor contact.

The structure and details of the product：
