ABB DSTV110 Connection Unit

1. Key Parameters

• Product Model: DSTV110
• Product Series: ABB AC500 Series Industrial Compact Connection Units (Small-Scale I/O Wiring Management)
• Core Function: Provides 12-channel mixed digital I/O (8 inputs + 4 outputs, fixed configuration); supports 24V DC signal transmission for low-power devices (≤300mA per output); integrates passive noise filtering and per-channel overcurrent protection; enables visual fault diagnostics via LEDs; supports DIN rail mounting; ensures stable signal transmission between field devices and AC500 digital I/O modules
• Electrical & Signal Specifications:

  Parameter	Details	Performance Metrics
  Signal Compatibility	- I/O Configuration: 12 channels (8 digital inputs + 4 digital outputs, fixed) - Supported Signals: Digital dry contact, NPN/PNP open-collector (24V DC) - Input Impedance: 2.5kΩ (24V DC input) - Output Current: Max 300mA per channel (continuous); 600mA peak per channel (10ms, for actuator inrush) - Switching Speed: <1.2ms (digital signal transition) - Input Voltage Range: 18V DC~30V DC	12-channel mixed design consolidates wiring for small I/O clusters (e.g., 6 photoelectric sensors + 2 limit switches + 3 relays + 1 indicator light); <1.2ms switching speed supports basic fast-response tasks (e.g., conveyor part detection); 300mA output capacity covers low-power actuators (small solenoids, indicator lights)
  Signal Protection & Filtering	- Overcurrent Protection: 4× 350mA slow-blow fuses (output channels, replaceable) - Noise Filtering: Passive RC low-pass filter (1.2kHz cutoff) for digital inputs; 50Hz/60Hz line noise suppression - ESD Protection: 8kV contact discharge / 15kV air discharge (IEC 61000-4-2) per channel - Reverse Polarity Protection: Diode-based (input channels and power supply, ≤24V DC)	Slow-blow fuses protect AC500 digital I/O modules (e.g., DSMB178) from shorted actuator wires; RC filters reduce electrical noise from nearby small motors or fans by 45%~60%; ESD protection safeguards against static discharge during installation/maintenance

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 75mm (W) × 55mm (H) × 16mm (D) - Mounting Type: DIN rail mount (EN 50022, 35mm, tool-less snap-on) - Housing Material: Flame-retardant thermoplastic (UL 94 V0) with thin conformal coating (IPC-CC-830, Class 2) - Weight: Approximately 38g - Indicators: 12× channel status LEDs (green = active; red = overcurrent/fault); 1× power LED (green = 24V DC present)	Ultra-compact form factor (16mm thickness) fits in dense AC500 cabinets or small wall-mounted enclosures (e.g., building automation sub-panels); lightweight design avoids DIN rail sagging; Class 2 conformal coating resists dust and non-corrosive moisture
  Environmental Ratings	- Operating Temperature Range: -20℃~+65℃ (-4℉~149℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 0.8g acceleration (IEC 60068-2-6) - Shock Resistance: 15g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 2); EN 61000-6-3 (emission: Class B)	-20℃~+65℃ range suits temperature-controlled industrial spaces and commercial buildings; vibration resistance prevents solder joint loosening in lightweight cabinets; Level 2 EMC immunity resists interference from small industrial equipment (e.g., office printers, small pumps)

• Compliance Specifications:

  Parameter	Details	Performance Metrics
  Safety & Compliance	- Safety Standards: CE, UL 508, CSA C22.2 No.14, IEC 61131-2 (industrial control) - Flame Retardancy: Housing (UL 94 V0); internal components (UL 94 V0) - RoHS Compliance: EU RoHS 2.0 (Restriction of Hazardous Substances)	UL 508/CSA certification ensures compliance with North American industrial safety requirements; flame-retardant design reduces fire risk in dense cabinet configurations; RoHS compliance meets global environmental regulations

2. Core Features

• Compact 12-Channel Mixed I/O (8 In + 4 Out): Consolidates 8 digital inputs and 4 digital outputs into a 75×55×16mm unit—saves 75% cabinet space vs. discrete terminal blocks; ideal for small automation systems (e.g., 4-sensor + 2-actuator packaging lines) or space-constrained enclosures (e.g., 19-inch 1U panels).
• Low-Power Output Capacity (300mA/Channel): Handles common low-power actuators (e.g., 24V DC indicator lights, 200mA small relays, 250mA micro-solenoids)—eliminates the need for external relays, reducing wiring complexity and component count for basic control tasks.
• Layered Fault Protection: Overcurrent fuses + ESD/reverse polarity/overvoltage safeguards—covers all common digital wiring faults (shorted sensors, incorrect polarity, electrostatic discharge); replaceable output fuses enable cost-effective repairs (no unit replacement needed for blown fuses).
• Simplified Installation & Diagnostics: Tool-less DIN rail mounting + channel-specific LEDs—installs in <1 minute (no brackets or specialized tools); green/red LEDs confirm normal operation or faults (e.g., red LED = overcurrent), allowing technicians to troubleshoot without multimeters.
• Industrial-Grade Reliability: UL 94 V0 flame-retardant housing + Class 2 conformal coating—withstands general industrial conditions (dust, non-corrosive moisture, temperature fluctuations) that damage unprotected units; -20℃~+65℃ operating range suits most indoor industrial and commercial environments.
• Seamless AC500 Integration: Optimized for ABB AC500 digital I/O modules (e.g., DSMB178 32-channel digital I/O)—connects directly via standard 24V DC wiring; no configuration or calibration needed; terminal spacing and labeling align with AC500 cabinet layouts, ensuring plug-and-play deployment.
• Cost-Effective Small-Scale Wiring: Delivers essential I/O consolidation and protection at a lower cost than high-density units—ideal for budget-conscious projects (e.g., startup manufacturing workshops, building automation sub-zones) that don’t require large I/O capacity.

3. Application Fields

• Light Manufacturing: Small-Line Automation:
  • Electronics Bench-Top Assembly: Connects sensors/actuators for manual assembly stations—8 input channels handle 6 photoelectric sensors (PCB presence) + 2 limit switches (fixture alignment); 4 output channels control 3 indicator lights + 1 small relay (test fixture); compact design fits in workstation-mounted control boxes, reducing bench clutter.
  • Small Packaging Machines: Centralizes wiring for basic packaging functions—8 input channels handle 5 photoeyes (package detection) + 3 limit switches (conveyor position); 4 output channels control 2 solenoid valves (sealing) + 2 conveyor relays; noise filtering prevents false triggers from conveyor motor interference.
• Process Control: Auxiliary Monitoring:
  • Chemical Plant Auxiliary Tanks: Connects status sensors for non-critical tanks—8 input channels handle 6 float switches (tank fill/empty) + 2 temperature switches (heater status); 4 output channels control 2 pump relays + 2 alarm buzzers; reverse polarity protection prevents damage from incorrect sensor wiring (common during maintenance).
  • Water Treatment Filtration Subsystems: Manages wiring for small filter units—8 input channels handle 5 pressure switches (filter clogging) + 3 flow switches (water flow); 4 output channels control 2 backwash valve relays + 2 fan relays; non-condensing humidity tolerance suits damp pump station environments.
• Building Automation: Commercial Space Controls:
  • Office HVAC Zone Sub-Panels: Connects sensors for small HVAC zones—8 input channels handle 5 occupancy sensors + 3 temperature switches (zone comfort); 4 output channels control 2 damper actuators + 2 fan relays; compact design fits in wall-mounted electrical panels, avoiding the need for large control boxes.
  • Retail Store Display Lighting: Manages digital controls for product displays—8 input channels handle 6 motion sensors (aisle traffic) + 2 light sensors (ambient light); 4 output channels control 4 display lighting relays; UL 94 V0 housing meets commercial building fire safety standards.
• Utility Substations: Secondary Monitoring:
  • Small Power Substations: Connects auxiliary status devices—8 input channels handle 5 breaker position switches + 3 cooling fan status sensors; 4 output channels control 2 fan relays + 2 indicator lights; -20℃~+65℃ range suits outdoor substation cabinets; vibration resistance prevents terminal loosening from transformer operation.
  • Solar PV Microgrids (100kW~500kW): Connects inverter auxiliary sensors—8 input channels handle 6 current switches (PV string status) + 2 voltage switches (DC bus); 4 output channels control 2 cooling fan relays + 2 status lights; EMC immunity resists interference from inverters, ensuring stable signal transmission.
