ABB DSTD197 connection unit

• Ports: RS-485 (half-duplex, 1200m max distance, 1200-115200 bps) and Ethernet (IEEE 802.3, 100 Mbps max).​

• Signal Compatibility: Handles 24 V DC digital signals; supports 0-10 V DC/4-20 mA analog signals (for temperature/pressure/flow sensors).​

• Supply Voltage: 24 V DC ±15% (built-in over/under-voltage protection).​

• Power Consumption: ~5 W (normal operation, energy-efficient).​

• Dimensions: 100×80×50 mm (L×W×H, compact for tight spaces).​

• Mounting: DIN-rail (EN 50022) or panel-mount (via screw holes).​

• Weight: ~200 g (lightweight for easy installation).​

• Temp Range: -20°C ~ +60°C (suitable for cold/hot industrial environments).​

• Humidity: 5%-95% (non-condensing).​

• Vibration/Shock: Complies with IEC 60068-2-6 (10-500 Hz, 1.5 g) and IEC 60068-2-27 (25 g, 11 ms).​

• Assembly Lines: Connects proximity sensors/actuators to PLCs for real-time part handling/positioning.​

• Quality Control: Links vision cameras to systems for fast defect-detection data transfer.​

• Chemical/Petrochemical Plants: Connects field instruments (pressure/temp/flow meters) to DCS (long-distance via RS-485).​

• Water/Wastewater Plants: Links pumps, valves, and level sensors to controls (digital for on/off; analog for level monitoring).​

• Power Plants: Connects turbine vibration sensors to systems for health monitoring.​

• Smart Grids: Facilitates data transfer between distributed energy resources (solar/wind) and grid management (via Ethernet).​

• Mounting: Slide onto DIN-rail (lock in place) or panel-mount with screws.​

• Wiring: Connect power (ensure polarity); use shielded cables for RS-485/Ethernet (reduce EMI); secure terminals.​

• Configuration: Set baud rate/IP address via software or DIP switches.​

• Inspection: Check for physical damage/loose connections; monitor status LEDs (green = normal, red = fault).​

• Cleaning: Remove dust with a dry soft brush (prevents overheating).​

• Firmware: Update to latest ABB releases (follow official guidelines for safety).​
