ABB DSTA121 Termination Unit

1. Key Parameters

• Product Model: DSTA121
• Product Series: ABB AC500 Series Industrial Terminal Termination Units (Wiring Management & Fault Protection)
• Core Function: Provides 16-channel terminal blocks for field sensor/actuator wiring termination; integrates basic signal filtering for digital/analog signals; offers overcurrent protection per channel (replaceable fuses); enables quick wiring diagnostics; supports DIN rail mounting for industrial cabinet integration; ensures stable signal transmission between field devices and AC500 I/O modules
• Terminal & Wiring Specifications:

  Parameter	Details	Performance Metrics
  Terminal Configuration	- Channel Count: 16 independent terminals (8 input channels + 8 output channels, fixed configuration) - Terminal Type: Screw-clamp terminals (accepts 24AWG~16AWG copper wires, max 1.5mm²) - Wiring Capacity: 1 wire per terminal (single-conductor connections) - Terminal Torque: 0.4~0.6 N·m - Marking: Pre-printed channel labels (IN1~IN8, OUT1~OUT8) + embossed terminal symbols (+/-/SIG)	16-channel design consolidates wiring for small-to-medium I/O clusters (e.g., 8 photoelectric sensors + 8 solenoid valves); screw-clamp terminals ensure vibration-resistant connections (no wire loosening in high-motion environments like conveyor lines); clear labeling minimizes cross-wiring errors (a top cause of automation downtime)
  Signal Protection & Filtering	- Overcurrent Protection: 16× 315mA slow-blow fuses (replaceable, per channel) - Signal Filtering: Passive RC filters (1kHz cutoff) for analog channels; 50Hz/60Hz line noise suppression for digital channels - ESD Protection: 6kV contact discharge (IEC 61000-4-2) per channel - Polarity Protection: Diode-based reverse polarity protection for DC inputs (≤24V DC)	315mA fuses prevent overcurrent damage to AC500 I/O modules (e.g., DSMB178 digital I/O) from shorted field wires; passive RC filters reduce analog signal noise (e.g., from VFDs) by 30%~50%; ESD protection safeguards against electrostatic discharge during wiring maintenance

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 90mm (W) × 75mm (H) × 55mm (D) - Mounting Type: DIN rail mount (EN 50022, 35mm, tool-less snap-on) - Housing Material: Flame-retardant thermoplastic (UL 94 V0) - Weight: Approximately 220g - Indicators: 16× channel status LEDs (green = normal signal; red = overcurrent/fuse blown); 1× power LED (green = unit powered)	Ultra-compact DIN rail design saves 40% cabinet space vs. discrete terminal blocks; fits in narrow enclosures (e.g., 19-inch 1U panels); LED per channel enables on-site technicians to quickly locate faults (e.g., red LED = shorted sensor wire) without multimeters
  Environmental Ratings	- Operating Temperature Range: -20℃~+65℃ (-4℉~149℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 0.8g acceleration (IEC 60068-2-6) - Shock Resistance: 15g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 2); EN 61000-6-3 (emission: Class B)	-20℃~+65℃ range suits unconditioned industrial spaces (e.g., workshop tool cabinets, outdoor utility boxes); vibration resistance prevents terminal loosening in mobile equipment (e.g., portable control panels); EMC immunity avoids interference from small motors or household appliances

• Compliance Specifications:

  Parameter	Details	Performance Metrics
  Safety & Compliance	- Safety Standards: CE, UL 508, CSA C22.2 No.14, IEC 61131-2 (industrial control) - Flame Retardancy: Housing (UL 94 V0); internal wiring (UL 1015, 105℃) - RoHS Compliance: EU RoHS 2.0 (Restriction of Hazardous Substances) - EMC Standards: IEC 61000-6-2 (immunity), IEC 61000-6-3 (emission)	UL 508/CSA certification ensures compliance with North American industrial safety requirements; flame-retardant design reduces fire risk in dense cabinet configurations; RoHS compliance meets global environmental regulations for hazardous substance limits

2. Core Features

• 16-Channel Centralized Termination: Consolidates 16 field wires (8 inputs + 8 outputs) into a single unit—eliminates scattered discrete terminals, reducing cabinet wiring time by 35% vs. traditional setups; fixed input/output configuration aligns with common automation I/O splits (e.g., 8 sensors + 8 actuators), simplifying system design.
• Per-Channel Fault Protection: 315mA slow-blow fuses + ESD/reverse polarity protection—safeguards AC500 I/O modules from common wiring faults (shorted sensors, incorrect polarity, electrostatic discharge); replaceable fuses enable easy maintenance (no unit replacement needed for blown fuses), reducing repair costs.
• Basic Signal Noise Suppression: Passive RC filters for analog signals + line noise suppression for digital signals—reduces electrical interference from industrial sources (e.g., VFDs, motor drives); ensures stable signal transmission for both digital (e.g., limit switches) and low-precision analog (e.g., temperature transducers) devices.
• Intuitive Fault Diagnostics: 16 individual status LEDs + clear labeling—technicians can quickly identify issues (red LED = blown fuse/overcurrent) without disconnecting wiring; reduces troubleshooting time from hours to minutes in medium-scale systems (e.g., 8-sensor packaging lines).
• Industrial-Grade Durability: UL 94 V0 flame-retardant housing + -20℃~+65℃ operating range—withstands harsh industrial conditions (dust, moisture, temperature fluctuations) that damage low-grade termination blocks; 15g shock resistance survives accidental impacts during cabinet maintenance, extending service life to 7+ years.
• Tool-Less Installation: Snap-on DIN rail mounting + easy-access fuse compartment—installs in <1 minute (no brackets or specialized tools); fuse compartment opens without removing the unit from the rail, enabling fast fuse replacement during maintenance (no wiring disconnection required).
• Seamless AC500 Integration: Designed for compatibility with AC500 I/O modules (e.g., DSMB178 digital I/O, DSMB340 analog I/O)—connects directly between field devices and PLC modules via standard wiring; no configuration or calibration needed, ensuring plug-and-play deployment in AC500 automation networks.

3. Application Fields

• Manufacturing Automation: Sensor/Actuator Wiring:
  • Electronics Assembly Lines: Terminates wiring for small-scale SMT peripherals—16 channels handle 8 photoelectric sensors (PCB presence) + 8 relay outputs (feeder locks); 315mA fuses protect AC500 DSMB178 modules from shorted feeder wires; LEDs confirm sensor status (green = active), simplifying line startup and maintenance.
  • Packaging Machines: Centralizes wiring for packaging line devices—terminates 6 limit switches (package alignment) + 2 photoeyes (label detection) + 8 solenoid valves (sealing/cutting); passive filters reduce noise from conveyor motors, avoiding false triggers of package detection sensors.
• Process Control: Auxiliary Signal Termination:
  • Food & Beverage Plants: Terminates wiring for filling machine sensors—16 channels handle 8 level sensors (tank fill level) + 8 valve actuators (product flow); reverse polarity protection prevents damage from incorrect sensor wiring (common during cleaning-related maintenance); UL 94 V0 housing meets food industry fire safety standards.
  • Water Treatment Facilities: Consolidates wiring for pump station auxiliaries—terminates 8 pressure switches (pump overload) + 8 relay outputs (pump starters); 5%~95% RH tolerance withstands damp pump station environments; LEDs enable fault checking via cabinet windows, avoiding unnecessary enclosure opening (reducing contamination risk).
• Energy & Utilities: Substation Auxiliary Wiring:
  • Small Power Substations: Terminates wiring for auxiliary equipment sensors—16 channels handle 8 temperature sensors (transformer cooling fans) + 8 relay outputs (fan controls); -20℃~+65℃ range suits outdoor substation cabinets; vibration resistance prevents terminal loosening from transformer operation.
  • Solar PV Microgrids: Centralizes wiring for inverter auxiliary devices—terminates 8 current sensors (PV string output) + 8 relay outputs (inverter cooling fans); EMC immunity resists interference from inverters, ensuring stable sensor readings for power monitoring.
• Building Automation: HVAC/Lighting Wiring:
  • Commercial Offices: Terminates wiring for HVAC zone controls—16 channels handle 8 temperature/humidity sensors (office zones) + 8 damper actuators; compact design fits in narrow wall-mounted electrical panels; clear labeling simplifies wiring for facility teams (no specialized automation expertise needed).
  • Retail Stores: Consolidates wiring for security and lighting systems—terminates 8 motion sensors (aisle lighting) + 8 relay outputs (light switches); ESD protection safeguards against static discharge during store maintenance (e.g., bulb replacement); DIN rail mounting simplifies integration into existing electrical panels.

The structure and details of the product：

 Please make an inquiry for more models
