ABB DSRF150 Mainframe

1. Key Parameters

• Product Model: DSRF150
• Product Series: ABB AC500 Series Industrial Mainframes (Control System Backbone)
• Core Function: Provides 10 standardized slots for AC500 modules (processors, I/O, signal processing); distributes regulated power to installed modules; enables high-speed data transmission via AC500 Local Bus; offers structural reinforcement for module stability; supports optional redundancy for power and data bus; ensures EMI shielding for system-level interference resistance
• Mechanical & Dimensional Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 482.6mm (W, 19-inch rack-mount) × 132mm (H, 3U) × 250mm (D) - Slot Configuration: 10 standard AC500 slots (compatible with single-slot modules: DSPC, DSMB, DSPB series) - Mounting Type: 19-inch rack-mount (EIA-310 standard) or wall-mount (via optional bracket) - Housing Material: Cold-rolled steel (1.2mm thickness) with powder coating (RAL 7035, light gray) - Weight: Approximately 4.5kg (empty); max 8kg (fully loaded with modules)	19-inch 3U design fits standard industrial racks; 10 slots support full AC500 system configurations (1 processor + 8 I/O + 1 expansion); steel housing provides structural rigidity to prevent module dislodgment

• Power Distribution Specifications:

  Parameter	Details	Performance Metrics
  Power Input	- Voltage Range: 24V DC ±10% (18V~28V DC) - Input Current: Max 15A (total system load) - Redundancy Support: 2 independent power input terminals (for 1+1 power redundancy) - Power Protection: Overvoltage (32V DC cutoff); overcurrent (18A auto-reset); reverse polarity (fuse-protected)	Dual power inputs enable redundant power supplies (e.g., 2× 24V DC PSUs), ensuring 99.99% power availability; overvoltage/overcurrent protection prevents module damage from electrical anomalies
  Power Distribution to Modules	- Output Voltage: 5V DC (regulated, ±5% tolerance) - Max Output Current per Slot: 2A - Total System Power Budget: 75W (5V DC × 15A) - Power Monitoring: Built-in current sense resistors (for slot-level power consumption monitoring via AC500 processor)	Regulated 5V DC ensures stable power for sensitive modules (e.g., DSPC155 processor, DSPB112 signal board); slot-level current monitoring alerts to overloads (e.g., short circuits in I/O modules)

• Data Bus & Communication Specifications:

  Parameter	Details	Performance Metrics
  Internal Data Bus	- Protocol: AC500 Local Bus (synchronous serial bus) - Data Transfer Rate: 100Mbps (full-duplex) - Bus Redundancy: Optional (via external bus redundancy module, ABB DSMR100) - Bus Isolation: 250V AC (between bus and power ground, 1 minute)	100Mbps bus ensures low-latency communication (≤100μs) between processor and I/O modules; bus isolation reduces EMI interference from power circuits

• Environmental & Protective Specifications:

  Parameter	Details	Performance Metrics
  Environmental Ratings	- Operating Temperature Range: -25℃~+70℃ (-13℉~158℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Ingress Protection (IP): IP20 (front panel; protects against finger contact and large dust particles) - Vibration Resistance: 10~500Hz, 0.5g acceleration (IEC 60068-2-6) - Shock Resistance: 10g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 3); EN 61000-6-3 (emission: Class B)	IP20 rating meets rack-mounted system safety standards; -25℃~+70℃ range suits unconditioned industrial racks; vibration resistance prevents loose module connections in factory environments

• Compliance Specifications:

  Parameter	Details	Performance Metrics
  Safety & Compliance	- Safety Standards: CE, UL 508 (industrial control equipment), CSA C22.2 No.14 - Flame Retardancy: Housing (UL 94 V0); internal wiring (UL 1015, 105℃) - RoHS Compliance: EU RoHS 2.0 (Restriction of Hazardous Substances) - EMC Standards: IEC 61000-6-2 (immunity), IEC 61000-6-3 (emission)	UL 508 certification ensures compliance with North American industrial safety requirements; RoHS compliance meets global environmental regulations

2. Core Features

• Scalable 10-Slot Configuration: Offers 10 standard AC500 slots—supports full system configurations (e.g., 1× DSPC155 processor + 6× DSMB I/O modules + 2× DSPB signal boards + 1× DSRB110 slot filler), eliminating the need for multiple small mainframes and reducing rack space usage by 40% vs. 2U 5-slot alternatives.
• Redundant Power Support: 2 independent power input terminals—enables 1+1 power redundancy (e.g., connecting two 24V DC power supplies); automatically switches to the backup supply if the primary fails, ensuring zero power interruption for critical processes (e.g., chemical batch production).
• High-Speed Stable Data Bus: 100Mbps AC500 Local Bus—ensures low-latency communication (≤100μs) between the processor and I/O modules, critical for time-sensitive applications (e.g., robotic welding, high-speed packaging); bus isolation reduces EMI interference from power circuits, avoiding data corruption.
• Industrial-Grade Structural Rigidity: 1.2mm cold-rolled steel housing with powder coating—provides robust support for fully loaded modules (max 8kg); resists rack vibration and accidental impacts (e.g., during module insertion/removal), preventing module dislodgment and backplane damage.
• Efficient Thermal Management: Optimized internal airflow design (front-to-back ventilation)—works with rack cooling fans to dissipate heat from high-power modules (e.g., DSPC171 processor, 30W); prevents hotspots and ensures all modules operate within -25℃~+70℃, extending component lifespan by 3~5 years.
• Seamless AC500 Integration: Standardized slot design and AC500 Local Bus—auto-detects all compatible modules (no manual configuration required); works with ABB Automation Builder software to monitor mainframe status (power consumption, bus health), reducing system setup time by 50% vs. third-party racks.
• Enhanced Safety & Compliance: UL 508/CSA C22.2 certification + IP20 protection—prevents electric shock (via insulated terminals) and restricts access to live components (via front panel); flame-retardant housing reduces fire risk in racks with other electrical equipment.

3. Application Fields

• Manufacturing Automation: PLC System Backbone:
  • Automotive Assembly Plants: Serves as the mainframe for AC500-based robot control systems—houses 1× DSPC155 processor (coordinating 10+ robots), 4× DSMB178 digital I/O modules (monitoring conveyor sensors), and 2× DSPB112 signal boards (processing encoder feedback); redundant power ensures no production downtime from power supply failures.
  • Electronics SMT Factories: Supports AC500 systems for SMT line control—10 slots accommodate 1× DSPC3121 processor, 5× DSMB340 analog I/O modules (tracking solder paste temperature), 2× DSPB120 display boards (HMI control), and 2× DSRB110 slot fillers; 100Mbps bus ensures real-time synchronization between modules.
• Process Control: DCS Auxiliary Racks:
  • Chemical Plants: Functions as an auxiliary mainframe for ABB DCS systems—houses 1× DSPC157 processor (controlling a reactor), 6× DSMB analog I/O modules (monitoring pressure/temperature), and 3× DSMX safety modules (SIL 2 functions); redundant power and bus isolation ensure reliability in corrosive environments.
  • Water Treatment Facilities: Supports AC500 systems for pump station control—10 slots hold 1× DSPC3001 processor, 4× DSMB digital I/O modules (controlling pumps), 3× DSMB analog I/O modules (measuring flow/pH), and 2× DSRB110 fillers; IP20 protection prevents dust ingress in outdoor pump station racks.
• Energy & Utilities: Control Station Infrastructure:
  • Solar PV Plants (100MW+): Serves as the mainframe for inverter control systems—houses 1× DSPC172 processor (managing 50+ inverters), 5× DSMB I/O modules (monitoring inverter status), 2× DSPB signal boards (processing voltage/current data), and 2× DSRB110 fillers; wide temperature range (-25℃~+70℃) suits desert rack enclosures.
  • Power Substations: Supports AC500 systems for auxiliary control (cooling fans, battery chargers)—10 slots accommodate 1× DSPC155 processor, 4× DSMB I/O modules (controlling substation equipment), 3× Modbus communication modules, and 2× DSRB110 fillers; EMC immunity resists interference from high-voltage switchgear.
• Infrastructure: Urban Automation Racks:
  • Metro Station Control Rooms: Functions as the mainframe for HVAC/lighting control—houses 1× DSPC3122 processor, 5× DSMB I/O modules (controlling station equipment), 2× DSPB120 display boards (HMI), and 2× DSRB110 fillers; 19-inch rack-mount design fits standard control room racks; redundant power ensures 24/7 operation.
