ABB DSQS168 communication interface

• • 1. Overview

    The ABB DSQS168 Communication Interface is an industrial communication module designed for ABB robotic controllers, automation systems, and process control equipment. It enables reliable data exchange between control units and external devices, providing stable, high-speed communication in demanding environments. It is commonly used in ABB IRB robot systems and various automation platforms.

    ---

    2. Key Technical Specifications (Typical)

    Electrical

    • Model: DSQS168

    • Type: Industrial communication interface module

    • Power Supply: 24 VDC (typical)

    • I/O Ports: Multiple digital communication channels

    • Data Transmission: Supports high-speed serial communication

    • Isolation: Electrical isolation between I/O and power supply

    • EMC Protection: Meets industrial EMC standards

    • Signal Type: Internal bus or external control signals

    Environmental

    • Operating Temperature: –10 °C to +55 °C

    • Storage Temperature: –40 °C to +70 °C

    • Humidity: 5%–95%, non-condensing

    • Vibration Resistance: Industrial-grade mechanical design

    Mechanical

    • Mounting: Slot-based installation inside robot controller cabinet

    • Material: Industrial metal or flame-retardant housing

    • Dimensions: Approx. 170 × 100 mm

    • Weight: Approx. 0.3 kg

    ---

    3. Features & Advantages

    • High-speed and stable communication performance

    • Excellent noise immunity

    • Compatible with various ABB controller generations

    • Modular plug-in design for easy replacement

    • High reliability and long service life

    • Supports multiple industrial communication methods

    ---

    4. Typical Applications

    • ABB IRB robot controller systems

    • Automation equipment communication expansion

    • Factory control system networking

    • PLC / DCS communication interface

    • Motion control and servo integration

    • Remote monitoring communication

    ---

    5. Notes & Precautions

    • Disconnect power before installing or removing the module.

    • Ensure the slot is clean before insertion.

    • Avoid operating in high-humidity or dusty environments.

    • Follow wiring labels to prevent connection errors.

    • Do not insert or remove the card under power.

    • Periodically check connectors for looseness.

    • Ensure adequate ventilation inside the control cabinet.

  •
  •
