ABB DSQC688 Profinet I/O Board

1. Key Parameters

• Product Model: DSQC688
• Order Code Reference: Typically paired with IRC5 Profinet expansion kits (e.g., 3HAC031702-001) and Profinet cables for procurement
• Product Series: ABB IRC5 Robot Controller Profinet Communication & I/O Boards
• Core Function: Enables Profinet communication between IRC5 controller and factory automation devices; provides local digital I/O for direct peripheral connection; supports real-time (IRT) and non-real-time data exchange
• Profinet Specifications:
  • Protocol Compliance: Profinet IRT (Isochronous Real-Time), Profinet RT (Real-Time), Profinet TCP/IP (non-real-time)
  • Data Transfer Rates: 100Mbps (full-duplex; compliant with IEEE 802.3u Fast Ethernet)
  • IRT Cycle Time: Configurable down to 1ms (for time-critical motion synchronization, e.g., robot-PLC coordination)
  • RT Cycle Time: 10ms~100ms (for standard I/O data exchange)
  • Max Nodes: Supports up to 128 Profinet devices per network segment (via daisy-chain or star topology)
  • Redundancy: Optional Profinet Media Redundancy Protocol (MRP) support (for fault-tolerant networks)
  • Compatibility: Compliant with Profinet V2.3; supports GSDML (Generic Station Description Markup Language) file for easy PLC integration (e.g., Siemens S7-1500, ABB AC500)
• Local I/O Specifications:
  • Digital Inputs (DI): 16 channels (24V DC; sinking/sourcing configurable via RobotStudio)
    • Input Voltage Range: 18V~30V DC (logic "1"); ≤5V DC (logic "0")
    • Input Current: 4mA~8mA (at 24V DC)
    • Response Time: ≤0.1ms (for fast sensor signals)
    • Debounce Time: Configurable (0.1ms~200ms; eliminates false triggers from noisy sensors)
  • Digital Outputs (DO): 16 channels (24V DC; sourcing type)
    • Output Voltage: 24V DC ±10% (energized state)
    • Maximum Output Current: 1A per channel; 8A total for all channels (overcurrent protected via PTC fuses)
    • Short-Circuit Protection: Built-in (automatic current limiting; no permanent damage)
• Electrical Specifications:
  • Power Supply (from IRC5 Backplane): 5V DC ±5% (typical current: 1.5A; maximum current: 2A)
  • Local I/O Power Supply: External 24V DC (18V~30V DC; isolated from backplane power; required for local DI/DO operation)
  • Power Consumption: ≤12W (backplane power) + ≤15W (local I/O power; full load)
  • Isolation: 2.5kVrms (between Profinet ports, local I/O, and IRC5 backplane; prevents ground loops)
  • EMC Immunity: Compliant with IEC 61000-6-2 (industrial environment); resistant to EMI from robot drives and welding equipment
• Mechanical Specifications:
  • Form Factor: PCB (Printed Circuit Board) with reinforced edge connectors (compatible with IRC5 controller’s communication slot)
  • Dimensions (W×H×D): 240mm × 180mm × 25mm (custom fit for IRC5 controller’s internal compartment)
  • Mounting: Slot-mounted (secures to IRC5 backplane via edge connectors; no additional screws)
  • Weight: Approximately 450g
  • Ports (on board edge):
    • 2× Profinet RJ45 Ports (100Mbps; M12 optional via adapter; supports line or ring topology)
    • 1× Local I/O Terminal Block (screw-type; for 24V DC power and 16 DI/16 DO connections)
  • LED Indicators (on board edge):
    • Power (PWR): Green (board powered on); Red (power fault)
    • Profinet Status (PN): Green (Profinet network connected); Blinking Green (data transmission); Red (network fault)
    • IRT Sync (IRT): Green (IRT synchronization active); Off (IRT disabled)
    • Local I/O (I/O): Green (local I/O active); Red (I/O short circuit/fault)
    • Fault (FLT): Amber (non-critical warning); Red (critical fault requiring shutdown)
• Environmental Ratings:
  • Operating Temperature Range: 0℃~+45℃ (32℉~113℉; matches IRC5 controller’s temperature limits)
  • Storage Temperature Range: -20℃~+70℃ (-4℉~158℉; no component degradation)
  • Humidity Tolerance: ≤85% RH (non-condensing, 40℃; suitable for manufacturing floors)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6; no solder joint failure)
  • Shock Resistance: 15g acceleration (11ms duration, IEC 60068-2-27; maintains electrical integrity)
• Compliance Standards: Profinet V2.3 (IRT/RT), IEC 61131-2 (industrial I/O), EN 61000-6-2 (EMC), UL 508 (industrial safety), CE, RoHS

2. Key Features

• IRC5-Profinet Seamless Integration: Custom-engineered for ABB IRC5 controllers—directly interfaces with the IRC5 backplane to exchange I/O data and motion commands, eliminating latency from third-party communication modules. Supports ABB RobotStudio configuration for Profinet parameters (e.g., IP address, IRT cycle time), simplifying setup.
• Profinet IRT/RT Support: Enables both time-critical IRT (cycle time down to 1ms) and standard RT communication—ideal for applications requiring synchronized motion (e.g., robot-PLC coordination in automotive assembly) and non-real-time data logging (e.g., production metrics).
• Dual Profinet Ports: Two RJ45 ports (with M12 adapter option) support line or ring topology (for MRP redundancy)—ensures network continuity if one port/cable fails, critical for mission-critical production lines (e.g., 24/7 electronics manufacturing).
• 32-Ch Local I/O (16 DI/16 DO): Integrates local digital I/O for direct connection to nearby peripherals (e.g., sensors, small actuators)—reduces the need for external I/O modules (e.g., DSQC652) and shortens wiring runs, lowering installation costs.
• 2.5kVrms Isolation: Industrial-grade isolation between Profinet ports, local I/O, and the IRC5 backplane protects sensitive communication circuits from ground loops and voltage transients (common in factory power grids)—ensures stable Profinet data transmission.
• Configurable Local I/O: Sinking/sourcing selectable for digital inputs (via RobotStudio) and PTC fuse protection for outputs—supports diverse peripheral types (e.g., NPN/PNP sensors, solenoid valves) without additional hardware adapters.
• Rugged Industrial Design: Reinforced PCB edges, EMC compliance, and wide temperature range (-20℃~+70℃ storage) withstand harsh manufacturing conditions (vibration, electrical noise, temperature swings)—extends service life to ≥8 years.

3. Application Fields

• IRC5-Profinet Factory Integration: Primary application—connects IRC5 robots to factory Profinet networks in:
  • Automotive Manufacturing: Enables IRT synchronization between IRB 6700 welding robots and Siemens S7-1500 PLCs; coordinates robot motion with conveyor speed (via Profinet RT) and transmits weld quality data (via non-real-time TCP/IP) to MES systems. Local I/O connects part presence sensors and welding torch cooling fans.
  • Electronics Production: Links IRB 120 pick-and-place robots to Profinet-based vision systems (e.g., ABB Vision Guide); uses IRT (1ms cycle time) to send real-time component position data, ensuring precise placement on PCBs. Local DO controls SMT feeder actuation.
• Time-Critical Motion Synchronization: Supports synchronized operations in:
  • Aerospace Assembly: Enables IRT communication between IRB 7800 drilling robots and external positioners; synchronizes robot spindle speed with positioner rotation (±0.1ms accuracy) to meet aerospace fastener hole tolerances.
  • Heavy Machinery Production: Coordinates IRB 8700 robots with Profinet-enabled hydraulic presses; uses Profinet RT to trigger press cycles based on robot part positioning, preventing collisions between robot and press.
• Peripheral-Rich Robot Cells: Expands I/O and communication for:
  • Food & Beverage Packaging: Connects IRB 360 delta robots to Profinet-compatible labelers and case sealers; local I/O monitors bottle presence sensors and controls reject mechanisms. Profinet TCP/IP transmits production counts to factory dashboards.
  • Warehouse Logistics: Integrates IRC5-controlled palletizing robots (IRB 660) with Profinet-based AGVs (Automated Guided Vehicles); uses Profinet RT to share pallet position data, optimizing AGV-robot material transfer.

4. Precautions

• IRC5 Exclusivity: Use exclusively with ABB IRC5 controllers. Never install in older ABB controllers (e.g., S4C+) or non-ABB systems—backplane pinout and communication protocols are incompatible, leading to board damage or network failure.
• Profinet Network Setup:
  • Configure Profinet parameters (IP address, subnet mask, IRT cycle time) via RobotStudio—mismatched settings (e.g., incorrect IRT cycle time) cause network desynchronization and data loss.
  • Use Profinet-certified cables (CAT5e or higher) for network connections. Maintain maximum cable length per Profinet guidelines (100m for line topology, 500m for fiber-optic extensions) to avoid signal degradation.
• Local I/O Power:
  • Use an isolated 24V DC power supply for local I/O (do not share with IRC5 backplane power or Profinet device power). Shared supplies cause voltage drops during high-output loads, leading to false I/O signals.
  • Ensure local I/O power is disconnected before wiring—short circuits during installation can damage the board’s I/O circuits.
• ESD Protection:
  • Wear an ESD wristband when handling the board—sensitive Profinet chips and I/O circuits are vulnerable to static discharge, which can cause permanent damage.
  • Store the board in anti-static packaging when not in use—avoid placing it on ungrounded surfaces (e.g., plastic tables).
• Maintenance Checks: Inspect quarterly (with IRC5 powered off):
  • Visually check Profinet ports for bent pins or corrosion—replace damaged cables and clean corroded ports with a dry brush.
  • Verify LED statuses during operation: Green PWR, Green PN (blinking for data), and no Red FLT indicate normal operation. Red PN or FLT requires network troubleshooting (e.g., check cable continuity, verify PLC Profinet settings).
  • Test local I/O via RobotStudio: Energize DO channels and measure voltage at terminals; activate DI channels (via sensors or test leads) and confirm status updates in RobotStudio
