ABB DSQC633 serial measurement unit

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB DSQC633 Serial Measurement Unit Product Data

Product Overview:

The ABB DSQC633 is a high-performance serial measurement unit designed for data acquisition and monitoring applications in ABB robotic control systems. Integrated with ABB robot controllers like the IRC5 series, this unit enables real-time data collection, signal processing, and measurement. The DSQC633 provides stable serial communication interfaces to collect data from various sensors and measurement devices, ensuring efficient system operation in industrial automation applications.

Key Technical Specifications:

• Model: DSQC633

• Application System: ABB IRC5 Robot Control Systems

• Measurement Type: Serial signal measurement, compatible with a variety of sensors and measurement devices

• Input Voltage: 24V DC

• Output Signal: Serial signal output (supports multiple communication protocols)

• Signal Interfaces:

  • 2 x RS232 Serial Ports

  • 1 x RS485 Serial Port

• Max Data Transmission Rate: 115200 bps

• Data Acquisition Precision: High-precision signal acquisition, supports multi-channel measurement

• Operating Temperature Range: 0°C to +45°C

• Storage Temperature Range: -20°C to +70°C

• Dimensions: Standard modular design, suitable for control cabinet installation

• Weight: Approx. 0.2 kg

• Installation Type: Standard circuit board installation, compatible with ABB control cabinets and racks

Product Advantages and Features:

1. Multi-Channel Data Acquisition: The DSQC633 supports multi-channel serial signal input, enabling simultaneous data acquisition from various sensors and measurement devices to meet diverse industrial requirements.

2. High Data Transmission Rate: Supports data transmission rates up to 115200 bps, ensuring fast processing and transmission of real-time measurement data for quick system response.

3. Strong Compatibility: Fully compatible with ABB robotic control systems (e.g., IRC5), supporting RS232 and RS485 serial communication interfaces, making it easy to integrate with external devices.

4. Precise Data Acquisition: Supports high-precision measurement and signal acquisition, ensuring accuracy in robotic system control and performance optimization, especially in precision motion control applications.

5. Modular Design: The DSQC633 is designed in a modular format, making it easy to install, maintain, and configure for various industrial applications.

6. Powerful Signal Processing: Equipped with an efficient processor, the DSQC633 quickly processes input signals, ensuring timely updates and data reliability for smooth system performance.

7. Reliable Serial Communication: Supports stable serial communication through RS232 and RS485 ports, ensuring seamless data exchange between systems and devices.

8. Stable Operational Performance: The unit operates reliably within a wide temperature range (0°C to +45°C), making it suitable for various industrial environments.

9. Compact and Energy-Efficient: Designed to be compact with low power consumption, the DSQC633 is ideal for environments with space and energy consumption constraints.

Application Areas:

1. Industrial Robot Control Systems: The DSQC633 is used as a core component in ABB robotic control systems (e.g., IRC5), enabling efficient robot control and feedback with precise data acquisition.

2. Automated Production Lines: It is widely used in automated production lines for acquiring data from sensors and ensuring precise control and real-time monitoring of the production process.

3. Precision Machining and Assembly: DSQC633 plays a key role in precision machining and assembly by providing real-time data collection and measurement, helping optimize robot motion paths and operation accuracy.

4. Welding and Coating Automation: Used in robotic welding and coating systems, DSQC633 collects data such as welding quality and coating thickness to ensure process accuracy and product quality.

5. Material Handling and Packaging: Powers robotic systems in material handling and packaging, ensuring efficient and reliable robot performance throughout the logistics and packaging processes.

6. Test and Experimental Equipment: Provides precise data acquisition and real-time analysis support for automated test equipment, meeting the high-precision requirements of testing and experimentation.

7. Energy and Environmental Monitoring: In energy and environmental monitoring systems, DSQC633 ensures accurate real-time data collection for better data analysis and decision-making.

Precautions:

1. Power Stability: Ensure the input power remains stable at 24V DC to prevent damage from voltage fluctuations. It's recommended to use an uninterruptible power supply (UPS) to avoid power interruptions.

2. Environmental Temperature: The unit should be installed in environments with temperatures ranging from 0°C to +45°C to avoid performance issues.

3. Signal Connection: Follow the RS232/RS485 standards when connecting signals to ensure stable data transmission and prevent signal loss or interference.

4. Module Replacement: If faults are detected in the DSQC633, follow ABB's technical manual for proper diagnosis and replacement to avoid system downtime.

5. Electrostatic Protection: Take necessary precautions against static electricity during installation and operation to prevent damage to the circuit board.

6. Regular Inspections: Regularly check the data acquisition accuracy and communication interfaces to ensure stable system operation, and clean the equipment to avoid dust buildup.

7. Installation Location: Ensure the device is installed in a well-ventilated area to prevent overheating or airflow issues that could affect long-term stability.
