ABB DSQC630 panel unit

1. Product Overview

The ABB DSQC630 Panel Unit is an HMI (Human-Machine Interface) module designed for ABB robots and automation control systems. It provides clear display of system status, robot operation data, alarms, and allows operators to perform system adjustments and monitoring. With its industrial-grade display, durable keys, and stable communication interface, the DSQC630 ensures reliable operation even in harsh industrial environments. It serves as an essential interface for interacting with robot controllers and automation equipment.

2. Technical Specifications

General

• Model: DSQC630

• Type: Panel Unit / HMI Display

• Manufacturer: ABB

• Usage: Robot and automation system operator interface

Display & Operation

• Display Type: Industrial backlit LCD

• Display Size: 5–7 inches (depending on version)

• Resolution: High-resolution industrial display (typical 640×480)

• Display Colors: Multi-color

• Operation: Keypad control + on-screen menu

• Display Functions:

  • System operating status

  • Error and alarm messages

  • Robot motion parameters

  • Control menus and settings

Communication

• Communication Interface: Serial port or dedicated ABB communication bus

• Connection: Direct connection to controller

• Compatible Controllers: ABB DSQC-series, including S4 and IRC5

• Power Supply: Provided by control cabinet (typical 24V DC)

Physical & Environmental

• Mounting: Panel-mounted

• Housing: Industrial impact-resistant enclosure

• Protection Rating: IP54 (front panel)

• Operating Temperature: 0°C to +55°C

• Storage Temperature: –25°C to +70°C

• Humidity: 5% to 95% non-condensing

• Vibration Resistance: Industrial-grade

3. Features & Advantages

1. Intuitive HMI interface for quick and clear system operation.

2. Rugged industrial design, suitable for harsh factory environments.

3. High compatibility with various ABB robot controllers.

4. Real-time monitoring improves productivity and system visibility.

5. Easy maintenance with modular panel construction.

6. Integrated diagnostic capabilities to quickly identify faults.

4. Application Areas

• Industrial robot control systems

• Automated production line monitoring

• Welding, assembly, and material handling robots

• Factory automation operator panels

• CNC machine front panels

• Automation cell (workstation) display units

5. Precautions

1. Avoid excessive impact on the screen or keypad during installation.

2. Ensure stable power input within specified limits.

3. Do not install the panel in environments with high humidity, dust, or corrosive gases.

4. Clean the screen only with a soft, non-corrosive cloth.

5. Disconnect power before wiring or disassembling the unit.

6. Use ABB-compatible cables to maintain stable communication.

7. If display or keypad malfunction occurs, inspect wiring and controller configuration.
