                                                                                                                                                                                                                                                              • ABB DSQC352A 3HAC020676-001 I/O Board

                                                                                                                                                                                                                                                                Product Overview

                                                                                                                                                                                                                                                                The ABB DSQC352A (3HAC020676-001) I/O Board is a DeviceNet / PROFIBUS-DP Gateway Communication Board designed for ABB industrial robot controller systems. It provides communication between ABB robot controllers and external PLC or fieldbus systems, allowing digital I/O signals to be exchanged through DeviceNet and PROFIBUS-DP networks. It is commonly used in ABB RobotWare systems for robot cell automation and field device integration.

                                                                                                                                                                                                                                                                Specifications

                                                                                                                                                                                                                                                                Parameter	Description
                                                                                                                                                                                                                                                                Brand	ABB
                                                                                                                                                                                                                                                                Model	DSQC352A
                                                                                                                                                                                                                                                                Part Number	3HAC020676-001
                                                                                                                                                                                                                                                                Product Type	I/O Communication Board / Fieldbus Gateway
                                                                                                                                                                                                                                                                Application	ABB Robot Controller
                                                                                                                                                                                                                                                                Communication Interface	DeviceNet / PROFIBUS-DP
                                                                                                                                                                                                                                                                PROFIBUS Speed	Up to 500 kbps
                                                                                                                                                                                                                                                                Power Supply	24 VDC
                                                                                                                                                                                                                                                                Mounting	Robot Controller Module / External I/O Unit
                                                                                                                                                                                                                                                                Function	Fieldbus Signal Exchange
                                                                                                                                                                                                                                                                Compatible System	ABB Industrial Robot Controllers
                                                                                                                                                                                                                                                                Battery	No Battery



                                                                                                                                                                                                                                                                Advantages & Features

                                                                                                                                                                                                                                                                • Provides DeviceNet and PROFIBUS-DP communication capability
                                                                                                                                                                                                                                                                • Enables ABB robot controllers to communicate with external PLC systems
                                                                                                                                                                                                                                                                • Supports digital input/output signal exchange
                                                                                                                                                                                                                                                                • Reliable industrial fieldbus communication
                                                                                                                                                                                                                                                                • Suitable for robotic automation cells
                                                                                                                                                                                                                                                                • Modular design for easy replacement and maintenance
                                                                                                                                                                                                                                                                • Improves integration between robots and factory control systems



                                                                                                                                                                                                                                                                Applications

                                                                                                                                                                                                                                                                • ABB Industrial Robot Systems
                                                                                                                                                                                                                                                                • Robot Cell Automation
                                                                                                                                                                                                                                                                • Welding Robots
                                                                                                                                                                                                                                                                • Material Handling Systems
                                                                                                                                                                                                                                                                • Assembly Lines
                                                                                                                                                                                                                                                                • PLC-Robot Communication
                                                                                                                                                                                                                                                                • Factory Automation Networks

                                                                                                                                                                                                                                                                Precautions

                                                                                                                                                                                                                                                                • Confirm compatibility with ABB robot controller model before installation.
                                                                                                                                                                                                                                                                • Verify DeviceNet / PROFIBUS network configuration.
                                                                                                                                                                                                                                                                • Check communication address settings.
                                                                                                                                                                                                                                                                • Ensure correct 24VDC power connection.
                                                                                                                                                                                                                                                                • Disconnect power before replacing the board.
                                                                                                                                                                                                                                                                • Handle with anti-static protection.
