ABB DSQC346E drive unit

1. Product Overview

The ABB DSQC346E Drive Unit is a key component in ABB industrial robots and automation systems, primarily used for motor control and driving actuators. The module provides precise speed, position, and torque control for high-performance motion of robots and automation equipment. The DSQC346E Drive Unit supports high-speed communication with the main controller and features overload protection, fault diagnostics, and status monitoring to ensure reliability and stability in industrial environments.

2. Technical Specifications

General

• Model: DSQC346E

• Type: Drive Unit

• Manufacturer: ABB

• Installation: Slot-mounted in control cabinet or robot control unit

Electrical

• Operating Voltage: 24V DC (logic power); motor drive voltage depends on model

• Output Type: Servo/AC motor drive output

• Interface: High-speed industrial bus

• Isolation: Logic control and power drive isolated for improved noise immunity

Performance

• Control Mode: Speed, position, and torque closed-loop control

• Response Time: High-speed dynamic response suitable for precision motion control

• Supported Functions:

  • Motor start/stop control

  • Torque, speed, and position closed-loop control

  • Fault detection and alarms

  • Temperature monitoring and overload protection

  • High-speed communication with main controller

Environmental

• Operating Temperature: 0°C to +55°C

• Storage Temperature: –25°C to +70°C

• Humidity: 5%–95% non-condensing

• Protection Class: IP20

• Vibration Resistance: Industrial-grade

3. Features & Advantages

1. Precise motion control with speed, position, and torque closed-loop capability.

2. High-speed dynamic response ensures stability and efficiency in automation processes.

3. Industrial-grade reliability with overload protection, temperature monitoring, and fault diagnostics.

4. Modular slot-mounted design for easy system integration, maintenance, and replacement.

5. High compatibility with ABB industrial robots and automation control systems.

6. Real-time status monitoring and alarms enhance operational safety.

4. Application Areas

• Drive control for ABB industrial robots

• Motor drive and actuator control in automated production lines

• PLC/DCS system drive interfacing

• Industrial robotic arms and material handling robot drives

• Automated assembly, welding, handling, and packaging lines

• Factory electrical control cabinets and automation equipment drive control

5. Precautions & Maintenance

1. Disconnect power before installation or maintenance.

2. Ensure input voltage and wiring comply with module specifications.

3. Avoid installation in high humidity, high temperature, or corrosive environments.

4. Regularly inspect slots, terminals, and cooling conditions.

5. Avoid strong vibrations or mechanical shocks to maintain module stability.

6. Do not exceed rated power and current specifications.

7. Use ABB-compatible control cabinets and bus interfaces for connection.
