ABB DSQC260 communication board

1. Product Overview

The ABB DSQC260 Communication Board is a core communication interface module in ABB industrial robots and automation systems. It enables reliable data transfer between the controller, robot system modules, external PLCs, upper-level computers, and industrial networks. Supporting high-speed bus communication and multiple industrial protocols, it ensures stable data transmission, suitable for coordinating robot systems with automation equipment in complex industrial environments.

2. Technical Specifications

General

• Model: DSQC260

• Type: Communication Board

• Manufacturer: ABB

• Installation: Slot-mounted in robot control cabinet

Electrical

• Operating Voltage: 24V DC

• Interface Types: Industrial bus interface, Ethernet interface (system-dependent)

• Supported Protocols: CAN, EtherCAT, Profibus, DeviceNet (protocol depends on system configuration)

• Data Rate: Up to 100 Mbps (depending on bus type)

• Isolation: Signal isolation for noise immunity

Performance

• Response Time: High-speed real-time data transmission

• Supported Functions:

  • Data exchange between controllers

  • I/O signal transmission

  • System status monitoring and diagnostics

• Storage: Non-volatile memory for configuration and parameters

Environmental

• Operating Temperature: 0°C to +55°C

• Storage Temperature: –25°C to +70°C

• Humidity: 5%–95% non-condensing

• Protection Class: IP20

• Vibration Resistance: Industrial-grade

3. Features & Advantages

1. High-speed and stable communication ensures coordinated operation of robot systems and controllers.

2. Multi-protocol support for various industrial bus and network requirements.

3. Modular design for easy installation, maintenance, and system upgrades.

4. Industrial-grade reliability with strong interference immunity.

5. Diagnostic functions support fault detection and system monitoring.

6. High compatibility with ABB robot control systems, PLCs, upper-level computers, and industrial networks.

4. Application Areas

• Communication interface for ABB industrial robot control cabinets

• Data exchange between controllers on automated production lines

• Networking of PLC/DCS systems with robot systems

• Industrial Ethernet, CAN bus, and fieldbus communications

• Industrial automation equipment monitoring and control

• Coordination between robot units and upper-level control systems

5. Precautions & Maintenance

1. Disconnect power before installation or maintenance.

2. Ensure bus interfaces and connections comply with board specifications.

3. Avoid installation in high humidity, high temperature, or corrosive environments.

4. Regularly inspect connectors and slots.

5. Avoid strong vibrations or mechanical shocks to ensure stable communication.

6. Use ABB-compatible control cabinets and bus interfaces for connection.

7. Ensure proper heat dissipation to maintain communication performance.
