ABB DSQC254 3HAA3563-APA backplane control board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• ABB DSQC254 3HAA3563-APA Backplane Control Board

  Introduction

  The ABB DSQC254 3HAA3563-APA is a Backplane Control Board used in ABB robot controllers, particularly in the IRC5 system. It serves as the central hub for communication and power distribution between different functional modules (I/O boards, measurement boards, safety modules, etc.). Acting as the "nervous system" of the controller, it ensures reliable synchronization and safe operation of the robot.

  ---

  Technical Specifications

  • Model: DSQC254

  • Part Number: 3HAA3563-APA

  • Type: Backplane Control Board

  • Functions:

    • Provides communication channels between controller modules

    • Distributes system power to modules

    • Manages bus signals and synchronization

    • Provides safety interlock and fault signal paths

  • Compatible Systems: ABB IRC5 robot controllers and related systems

  • Power Supply: 24 V DC (distributed from controller main power)

  • Interfaces: Multi-slot backplane connections, supporting DSQC modules

  • Operating Conditions: 0 to +55 °C, ≤95% RH (non-condensing)

  • Mounting: Rack/backplane installation inside control cabinet

  • Certifications: CE, UL

  ---

  Features & Advantages

  • Central communication backbone for all modules.

  • Stable power distribution to ensure reliable operation.

  • Modular architecture supports multiple DSQC modules and easy maintenance.

  • Industrial-grade design for long-term high-load operation.

  • Integrated safety loop and fault transmission.

  ---

  Applications

  • ABB industrial robot controllers (e.g., IRC5)

  • Automation production line management

  • Multi-module robotic workstations

  • High-speed precision motion control

  • Safety-critical automation applications

  •

 Please make an inquiry for more models
