ABB DSQC238 Resolver Filter Board

Introduction

The ABB DSQC238 Resolver Filter Board is a critical module in ABB industrial robot control systems, designed to filter and process resolver signals. A resolver is a position sensor used in servo motors and robot joints for precise position feedback. This board ensures clean and interference-free signals, enabling high accuracy and stable motion control of ABB robots.

Features & Functions

• Resolver signal filtering – eliminates EMI and high-frequency noise.

• High-precision feedback – ensures accurate motor/joint angle detection.

• Robust & reliable – industrial-grade design for long-term use.

• Strong compatibility – supports multiple ABB controllers and servo systems.

• Easy maintenance – modular plug-in design for quick replacement.

Technical Specifications

• Model: DSQC238

• Type: Resolver Filter Board

• Function: Resolver signal filtering and interface management

• Power Supply: From main control unit (low power consumption)

• Mounting: Slot mounting in controller/servo drive cabinet

• Compatible Systems: ABB IRC5 / S4C+ / dedicated servo controllers

• Operating Environment:

  • Temperature: 0–55℃

  • Humidity: 5–90% non-condensing

• Protection: Overload and interference shielding

Applications

• Industrial robots – resolver signal filtering for joint motors.

• Servo motor control – ensures clean and stable feedback.

• Automated production lines – precise motion and positioning tasks.

• CNC machinery – high-accuracy axis control.

• Process control systems – stable continuous motion environments.

Installation & Maintenance Notes

1. Always power off before installation or replacement.

2. Ensure secure connection of resolver cables and connectors.

3. Use anti-static protection when handling.

4. Monitor cooling and avoid overheating.

5. Use genuine ABB spare parts for best performance.
