ABB DSQC224 Analog I/O Module

Introduction

The ABB DSQC224 Analog I/O Module is an expansion module used in ABB industrial robot controllers to handle analog signal input and output. It allows the controller to acquire analog signals from sensors and external devices, while also outputting analog control signals to actuators such as servo valves or frequency converters.

Technical Specifications

• Model: DSQC224

• Type: Analog Input/Output Module

• Functions:

  • Multiple channels for analog input and output

  • Supports both voltage and current signals

  • Converts signals for data exchange between robot and external devices

• Input/Output Ranges:

  • AI: typically 0–10 V / 4–20 mA

  • AO: typically 0–10 V / 4–20 mA

• Resolution: 12-bit or higher (depending on system configuration)

• Compatible Systems: ABB S4C / S4C+ controllers

• Power Supply: 24 VDC from controller cabinet

• Operating Environment:

  • Temp: 0–55℃

  • Humidity: 5–90% non-condensing

• Mounting: Rack-mounted inside controller

Features & Benefits

• Versatile signal support – works with both voltage and current type signals

• High accuracy – precise acquisition with high resolution

• Modular design – easy expansion and replacement

• Real-time response – suitable for precision control applications

• Enhanced flexibility – allows integration with complex process equipment

Applications

• Robotics – communication with sensors and actuators

• Process control – acquisition of temperature, pressure, flow signals

• Automation lines – control of drives, valves, and analog devices

• Automotive industry – paint spraying, welding, testing systems

• Electronics industry – high-precision testing and assembly processes

Installation & Maintenance Notes

1. Always power off before installing or replacing modules.

2. Ensure correct wiring of voltage/current signals to avoid damage.

3. Regularly inspect connectors and cables for proper contact.

4. Use shielding or isolation to minimize interference.

5. Always use genuine ABB modules for compatibility and reliability.
