ABB DSQC104 YB161102-AE Circuit Board Resolver Digital Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB DSQC104 YB161102-AE Circuit Board / Resolver Digital Board

1. Product Description & Technical Specifications

Model: DSQC104 / YB161102-AE
Type: Circuit Board / Resolver Digital Board
Function:
The DSQC104 is a key component in ABB robot control systems. It processes resolver signals from servo motors and converts them into digital signals for the controller. It provides precise motor position and speed information, enabling high-precision robotic motion control.

Technical Specifications:

• Board Type: Digital resolver circuit board

• Input Signal Type: Resolver differential signals

• Output Signal Type: Digital encoded signals

• Power Supply: 5 VDC / 24 VDC (depending on system configuration)

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -20°C to +70°C

• Interface Type: Dedicated connector compatible with ABB robot controllers

• Installation: Plug-in slot in ABB robot control cabinet

• Standards: CE

2. Advantages & Key Features

1. High-precision signal conversion
   Converts resolver analog signals to digital signals quickly and accurately for high-precision control.

2. High reliability
   Industrial-grade design resistant to vibration and interference, ensuring stable long-term operation.

3. Plug-and-play
   Fully compatible with ABB control cabinets, easy installation and replacement.

4. Enhances system performance
   Accurate acquisition of motor position and speed improves robotic motion precision and responsiveness.

5. Reduces maintenance costs
   Modular design simplifies troubleshooting and replacement, lowering maintenance complexity.

3. Typical Applications

• ABB industrial robot control systems

• Motion control for industrial automation production lines

• High-precision robotic arms and automated equipment

• Factory automation and assembly line control

• CNC and specialized machinery motion control

4. Precautions

1. Power off before installation or removal.

2. Avoid static discharge; wear an anti-static wrist strap when handling.

3. Ensure connectors are securely inserted to prevent signal loss.

4. Operating temperature and humidity must be within the allowed range.

5. Regularly check board condition, avoiding dust or corrosion accumulation.

6. Follow ABB control cabinet and robot operation manuals during use.

The structure and details of the product：
