ABB DSQC1015 3HAC048858-001/03 safety module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB DSQC1015 3HAC048858-001/03 Safety Module Product Data

Product Overview:

The ABB DSQC1015 3HAC048858-001/03 Safety Module is a high-performance safety control module designed for industrial automation systems. It is specially developed for ensuring the safety of both equipment and personnel in applications such as emergency shutdowns, fault protection, and safety monitoring. The module provides real-time safety state monitoring and can take immediate action in case of potential hazards, ensuring the efficient and safe operation of production lines.

Key Technical Specifications:

• Input Type: Supports various safety input signals such as emergency stop, switch signals, etc.

• Output Type: Digital safety output signals, such as emergency stop outputs

• Operating Voltage: 24V DC (typical)

• Response Time: < 20ms

• Operating Temperature Range: -20°C to +60°C

• Storage Temperature Range: -40°C to +85°C

• Protection Class: IP20

• Safety Level: Complies with international standards ISO 13849-1 and IEC 61508

• Connection Interface: Supports industrial communication protocols like PROFIBUS, Modbus

• Input Signal Voltage Range: 24V DC

• Output Signal Voltage Range: 24V DC

• Dimensions: W 120mm x H 130mm x D 80mm

• Weight: Approximately 350g

• Mounting Method: DIN rail mounting

• Max Input Channels: Up to 16 safety input channels

• Max Output Channels: Up to 16 safety output channels

• Certifications: CE, UL, CSA, and other international safety certifications

Product Advantages and Features:

1. High Safety Performance: The DSQC1015 complies with ISO 13849-1 and IEC 61508 safety standards, offering high-level safety features to ensure immediate action in case of emergency, such as emergency shutdown and fault protection.

2. Real-Time Fault Monitoring and Processing: The module monitors and detects safety signals in real-time and takes immediate actions when anomalies are detected, preventing potential safety risks.

3. Multi-Channel Input/Output Support: The module supports up to 16 safety input channels and 16 safety output channels, meeting complex safety control requirements for multiple devices.

4. Fast Response Time: With a response time of less than 20ms, the DSQC1015 ensures rapid detection of hazardous signals and immediate response to prevent accidents.

5. Wide Application Compatibility: Supports common industrial communication protocols like PROFIBUS and Modbus, enabling easy integration with existing control systems and enhancing system flexibility.

6. Modular Design and Easy Installation: The module is designed for DIN rail mounting, facilitating quick installation and maintenance. The modular design also allows for easy future expansion and upgrades.

7. High Reliability and Stability: Built with high-quality industrial-grade materials, the module offers excellent electromagnetic interference resistance, ensuring reliable operation in harsh industrial environments.

8. International Certifications: The DSQC1015 meets CE, UL, and CSA certifications, making it suitable for global industrial automation applications, ensuring compliance with relevant safety regulations and standards.

Application Areas:

1. Robot Safety Control: The DSQC1015 can be used in robotic automation systems for emergency stops, collision detection, and other safety features, ensuring operator safety during robotic operations.

2. Automated Production Lines: It is applied in safety control systems of automated production lines, monitoring safety input signals in real-time and ensuring the safety of production processes.

3. Process Control: In industries such as chemicals, pharmaceuticals, and energy, the DSQC1015 monitors key safety points in production processes, ensuring the safety of equipment and the working environment.

4. Machine Equipment Protection: The module is used for machine equipment safety protection, including emergency stops and fault alarms, ensuring automatic shutdown of equipment during anomalies, preventing damage and injury.

5. Hazardous Environment Monitoring: In high-risk environments such as mining, metallurgy, and petrochemicals, the DSQC1015 is used for monitoring and protecting safety, ensuring the safety of personnel and equipment.

6. Building Automation Systems: The module is used in building automation safety controls such as fire alarms, access control, and emergency lighting, ensuring the safety of the building.

Precautions:

1. Power Supply Requirements: Ensure stable 24V DC power supply. Power instability may lead to module failure or incorrect safety response.

2. Temperature Control: Ensure the working temperature stays within -20°C to +60°C to avoid damage or malfunction in extreme temperatures.

3. Signal Connection: Ensure correct connection of safety input and output signals to avoid miswiring or short circuits, ensuring stable signal transmission.

4. Electromagnetic Interference Protection: While the module is designed with EMI protection, additional shielding may be needed in high-EMI environments for stable operation.

5. Regular Checks and Maintenance: Periodically check the module’s status and connections to ensure reliable operation, particularly in high-load or harsh environments, more frequent checks are required.
