ABB DSQC 236G YB560103-CD/24 Power Supply Driver Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DSQC 236G (YB560103-CD/24) is a Power Supply Driver Board designed for ABB industrial robot controllers, such as the IRC5 series, and servo drive systems. It distributes and controls the power supply within the controller, ensuring stable operation of servo drives and robot components. The DSQC 236G provides efficient power management and protection, making it a core power module in the robot controller for reliable and long-term operation.

2. Technical Specifications

• Model: DSQC 236G / YB560103-CD/24

• Type: Power Supply Driver Board

• Compatible System: ABB IRC5 robot controllers and servo drive systems

• Input Voltage: 24 V DC

• Output Voltage: Distributed according to controller and drive requirements

• Output Current: Matched to drive and controller modules

• Operating Temperature: 0℃ ~ +50℃

• Storage Temperature: -25℃ ~ +70℃

• Mounting: Controller internal slot or fixed installation

• Dimensions: Standard controller board design

• Weight: ~1.2 kg

• Protection Degree: IP20

• Reliability: Industrial-grade design for long-term continuous operation

• Additional Features: Overcurrent and overvoltage protection, status indication

3. Key Features & Advantages

1. Efficient power driving — Provides stable voltage and current to ensure proper operation of servo drives and controller modules.

2. Modular design — Plug-in installation for easy maintenance, replacement, and upgrades.

3. Strong compatibility — Designed for ABB IRC5 controllers and servo drives to ensure system stability.

4. High reliability — Industrial-grade design supports long-term operation and transient overload protection.

5. Safety protection — Built-in overcurrent/overvoltage protection and status indicators enhance system safety.

6. Compact structure — Saves internal space and improves system integration.

4. Typical Applications

• Power management for ABB IRC5 robot controllers

• Industrial robot servo drive systems

• Power distribution and drive control in automated production lines

• Factory automation and high-precision motion control systems

• Robot and automation equipment maintenance and upgrades

5. Precautions & Recommendations

1. Power off the controller before installation or removal to ensure safety.

2. Ensure input/output voltage and current match the controller and drive requirements to avoid damage.

3. Avoid high temperature, humidity, dust, or corrosive environments.

4. Secure the module firmly to prevent vibration or poor contact.

5. Installation and maintenance should be performed by qualified personnel.

6. Regularly check the module and status indicators to ensure long-term reliable operation.

The structure and details of the product：

Please make an inquiry for more models
