ABB DSQC-236C YB560103-CC Servo Amplifier Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DSQC-236C YB560103-CC Servo Amplifier Board is used in ABB industrial robots and automation systems. It controls the power output to servo motors to achieve precise position, speed, and torque control. As a core component of ABB robot servo systems, it works together with DSQC series control boards, drive units, and sensor modules to ensure high-precision, stable, and responsive multi-axis robot motion.

2. Technical Specifications

• Model: DSQC-236C

• Part Number: YB560103-CC

• Type: Servo Amplifier Board

• Compatible System: ABB industrial robots and servo systems

• Control Type: Position, speed, torque closed-loop control

• Input Signal: Control board output and resolver/encoder feedback signals

• Output Power: Configurable according to servo motor specifications

• Operating Temperature: 0℃ ~ +50℃

• Storage Temperature: -25℃ ~ +70℃

• Mounting: Modular installation in control or drive cabinet

• Dimensions: Modular board design

• Weight: ~1.8 kg

• Protection Degree: IP20

• Additional Features: Overcurrent protection, overvoltage protection, overtemperature protection, LED status indicators, fault alarms

3. Key Features & Advantages

1. High-performance servo control — Supports position, speed, and torque closed-loop control for precise motion.

2. Multi-axis coordination — Works with other servo amplifier boards and control boards for synchronized multi-axis control.

3. Modular design — Plug-in installation for easy maintenance, upgrade, and replacement.

4. Industrial-grade reliability — Suitable for high temperature, vibration, and long-term industrial operation.

5. Multiple protection mechanisms — Overcurrent, overvoltage, and overtemperature protection ensure safe and stable operation.

6. Visual status indicators — LEDs display operational status and faults for quick diagnostics and maintenance.

4. Typical Applications

• Servo systems in ABB industrial robots

• Servo drive control for automated production lines

• High-precision motion control in multi-axis robots and automation equipment

• Factory automation, manipulators, and servo device control

• Automation equipment maintenance and system upgrades

5. Precautions & Recommendations

1. Power off the controller before installing or removing the servo amplifier board to ensure safety.

2. Ensure the board interfaces match the servo motor and control board.

3. Avoid high temperature, humidity, dust, or corrosive environments.

4. Secure the module firmly to prevent vibration or poor contact.

5. Installation and maintenance should be performed by qualified personnel.

6. Regularly check LED indicators and module temperature to ensure long-term stable operation.
