ABB DSMC112 57360001-HC Controller Module

1. Key Parameters

• Product Model: DSMC112 57360001-HC
• Product Series: ABB DSM Series Industrial Controller Modules (Distributed Automation Core)
• Core Function: Executes IEC 61131-3 control programs (LD/FBD/ST/IL/CFC); coordinates distributed I/O modules; processes real-time field data; communicates with SCADA/DCS via multi-protocols; supports redundancy for high availability; provides built-in safety functions (SIL 2 compliant)
• Processor & Memory Specifications:

  Parameter	Details	Performance Metrics
  Processor	- Type: 32-bit ARM Cortex-A9 (dual-core, 1.0GHz) - Floating-Point Unit (FPU): Integrated (supports 32/64-bit floating-point operations) - Control Cycle: Min 1ms (for 1000 I/O points) - Instruction Execution Speed: 1.5 DMIPS/MHz	Dual-core processor handles concurrent control tasks (e.g., process regulation + data logging); FPU enables precise calculations for complex processes (e.g., PID temperature control)
  Memory	- RAM: 512MB DDR3 (industrial-grade, ECC error correction) - Flash Memory: 1GB (for program storage, non-volatile) - Expandable Storage: Supports microSD card (up to 32GB, for log files/backup) - Data Retention: Flash memory (10+ years at 25℃); RAM (backup via supercapacitor, 72h without power)	ECC RAM prevents data corruption from electrical noise; supercapacitor backup ensures no loss of critical process data during short power outages

• Communication & I/O Integration Specifications:

  Parameter	Details	Performance Metrics
  Built-In Communication Ports	- Industrial Ethernet: 2× 10/100/1000 Mbps (PROFINET IO IRT, EtherNet/IP, Modbus TCP) - Serial: 2× RS-485 (Modbus RTU, ASCII; up to 115.2kbps) - Expansion Port: 1× PCIe Mini (for optional communication cards, e.g., Profibus DP) - Synchronization Port: 1× Ethernet (for controller redundancy, 100Mbps)	Dual Gigabit Ethernet supports redundant network architectures; PROFINET IO IRT ensures <1ms synchronization with distributed I/O (e.g., DSMB178)
  I/O Integration	- Supported I/O Modules: ABB DSMB series (digital/analog I/O), DSMX series (specialized I/O) - Max I/O Points: 8192 (distributed, via PROFINET/EtherNet/IP) - I/O Update Rate: Min 0.5ms (for 1000 points) - I/O Isolation: 500V AC (between controller and I/O modules)	Large I/O capacity covers complex systems (e.g., 500-sensor manufacturing lines); fast update rate ensures real-time response to field changes (e.g., emergency stop signals)

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 140mm (W) × 100mm (H) × 60mm (D) - Mounting Type: 35mm DIN rail (EN 50022, tool-less) - Housing Material: EMI-shielded aluminum alloy (UL 94 V0 coating) - Weight: Approximately 450g - Indicators: 4× status LEDs (power/run/fault/redundancy); 2× Ethernet link LEDs	Aluminum alloy housing enhances heat dissipation and mechanical strength; EMI shielding reduces interference from VFDs/motors; tool-less DIN rail mounting simplifies installation
  Environmental Ratings	- Operating Temperature Range: -25℃~+70℃ (-13℉~158℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 1.5g acceleration (IEC 60068-2-6) - Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 4); EN 61000-6-3 (emission: Class A)	Level 4 EMC immunity withstands extreme electrical interference (e.g., welding arcs, transformer inrush); wide temperature range suits outdoor/harsh industrial sites (e.g., oil refineries, steel mills)

• Safety & Compliance Specifications:

  Parameter	Details	Performance Metrics
  Safety Functions	- Safety Integrity Level (SIL): 2 (per IEC 61508) - Built-In Safety Functions: Emergency stop (ES), safe torque off (STO), safe speed monitoring (SSM) - Safety Communication: Supports PROFINET IO Safety (PROFIsafe)	SIL 2 compliance meets safety requirements for critical processes (e.g., chemical reactor shutdown); PROFIsafe enables safe communication with distributed safety I/O
  Compliance Standards: CE, UL 508, CSA C22.2 No.14, IEC 61131-3 (control programming), IEC 61508 (functional safety), RoHS, ISO 9001

2. Core Features

• High-Performance Dual-Core Processing: 1.0GHz ARM Cortex-A9 dual-core processor with ECC RAM—handles complex control tasks (e.g., 100+ PID loops for temperature/pressure regulation) and concurrent data processing (e.g., real-time monitoring + historical logging) without performance bottlenecks.
• Multi-Protocol Industrial Communication: Dual Gigabit Ethernet (PROFINET IO IRT, EtherNet/IP, Modbus TCP) and RS-485—integrates with diverse automation ecosystems (e.g., Siemens PROFINET SCADA, Rockwell EtherNet/IP DCS) and legacy devices (e.g., Modbus RTU sensors), eliminating protocol gateways.
• Scalable Distributed I/O: Supports up to 8192 distributed I/O points via DSMB/DSMX modules—scales from small systems (e.g., 50-point workshop control) to large-scale processes (e.g., 5000-point chemical plants) without replacing the controller core.
• High Availability Redundancy: Dedicated synchronization port for controller redundancy (1:1 hot standby)—automatically switches to the standby controller in <100ms if the primary fails, ensuring zero downtime for mission-critical processes (e.g., power grid control, pharmaceutical batch production).
• SIL 2 Functional Safety: Built-in safety functions (ES/STO/SSM) and PROFIsafe support—meets safety standards for hazardous processes (e.g., explosive chemical handling); eliminates the need for separate safety controllers, reducing system complexity and cost.
• Robust EMI-Shielded Housing: Aluminum alloy housing with EMI shielding (Level 4 EMC immunity)—withstands extreme electrical noise (e.g., near high-voltage switchgear, welding robots) that disrupts standard controllers, ensuring stable operation.
• IEC 61131-3 Programming: Supports all IEC 61131-3 languages (LD/FBD/ST/IL/CFC) via ABB Automation Builder—enables flexible programming for different user skills (e.g., ladder logic for electricians, structured text for software engineers) and easy migration from legacy PLCs.

3. Application Fields

• Manufacturing Automation: Complex Production Line Control:
  • Automotive Body Shops: Controls robotic welding cells (10+ robots) and conveyor synchronization—dual-core processor handles concurrent robot motion control and I/O monitoring; PROFINET IO IRT ensures <1ms synchronization to avoid weld misalignment.
  • Electronics Semiconductor Lines: Regulates temperature, pressure, and vacuum for wafer processing—FPU enables precise PID control (±0.1℃ temperature accuracy); SIL 2 safety functions trigger emergency shutdown if process parameters exceed safe limits.
• Process Control: Hazardous & Precision Processes:
  • Chemical Reactors: Manages batch reactions (e.g., polymer synthesis) with 50+ PID loops—redundant controllers ensure no downtime during batch runs; PROFIsafe communicates with safety valves to prevent overpressure.
  • Pharmaceutical Bioreactors: Controls pH, dissolved oxygen, and agitation speed—ECC RAM prevents data corruption (critical for batch compliance); non-volatile flash stores audit trails for FDA 21 CFR Part 11 compliance.
• Energy & Utilities: Grid & Renewable Control:
  • Power Distribution Grids: Monitors and controls medium-voltage switchgear—dual Ethernet ports connect to utility SCADA and local HMI; wide temperature range (-25℃~+70℃) suits outdoor substations.
  • Wind Farm Collectors: Coordinates 50+ wind turbines’ power output—Modbus TCP communicates with turbine controllers; expandable microSD storage logs energy production data for grid compliance.
• Infrastructure & Water Treatment: Critical Utility Control:
  • Municipal Water Treatment Plants: Controls filtration, disinfection, and pump systems—distributed I/O integration covers 1000+ sensors/actuators; redundancy ensures no service interruption (critical for public health).
  • Airport Baggage Handling: Coordinates conveyor sorting systems—fast I/O update rate (0.5ms) ensures accurate baggage routing; EMI shielding resists interference from airport radar and electrical systems.

The structure and details of the product：
