ABB DSMB133 Memory Board Module

1. Key Parameters

• Product Model: DSMB133
• Product Series: ABB S800 I/O Compact Memory Board Modules (Data Storage & Caching)
• Core Function: Provides non-volatile storage for control logic, configuration files, and short-term process logs; offers error-correcting volatile memory for real-time data; supports data backup/restore via S800 bus; enables basic fault detection (e.g., memory errors); integrates with S800 controllers for low-latency access
• Memory & Storage Specifications:

  Parameter	Details	Performance Metrics
  Non-Volatile Memory (NVM)	- Type: Industrial-grade Single-Level Cell (SLC) Flash

• Capacity: 64MB (fixed, no expansion slot)
• Data Retention: 15 years (at 25℃, no power)
• Write Cycles: 100,000+ program/erase cycles (per sector)
• Access Speed: 25MB/s read, 12MB/s write | SLC Flash ensures stable performance for moderate update frequencies (e.g., daily recipe changes); 64MB capacity suits mid-scale needs (e.g., 30+ control programs) |
  | Volatile Memory (RAM) | - Type: Error-Correcting Code (ECC) RAM
• Capacity: 16MB (for real-time data caching)
• Backup: Single 3V lithium battery (48-hour retention without main power)
• Error Correction: Single-bit error correction, double-bit error detection | ECC RAM prevents data corruption from electrical noise; 48-hour backup preserves critical data (e.g., batch counts) during short power outages |
  | Data Integrity Features | - Checksum Validation: CRC-32 for all stored files (logic, configurations)
• Wear Leveling: Basic static wear leveling (extends Flash lifespan by 30%)
• Bad Block Management: Passive bad block detection (flags corrupted blocks via S800 bus) | CRC-32 validation ensures no corrupted data is loaded into controllers; simple wear leveling suits low-to-medium write-frequency applications |
• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 80mm (W) × 100mm (H) × 15mm (D) (ultra-thin PCB form factor)

• Mounting: Screw-mount to S800 sub-rack chassis (M2.5 screws, 4 mounting points)
• Material: FR-4 glass-reinforced epoxy (UL 94 V0) with conformal coating (IPC-CC-830 Class 2)
• Connectors: 1× DIN 41612 backplane connector; 1× battery access port
• Weight: Approximately 80g | Ultra-thin design fits compact S800 sub-racks; conformal coating resists dust and mild moisture |
  | Environmental Ratings | - Operating Temperature Range: -20℃~+60℃ (-4℉~140℉)
• Storage Temperature Range: -40℃~+85℃ (-40℉~185℉)
• Humidity Tolerance: 5%~95% RH (non-condensing, 40℃)
• Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6)
• Shock Resistance: 15g (11ms half-sine, IEC 60068-2-27)
• EMC Compliance: EN 61326-3-1 (emission: Class B; immunity: Level 2) | Withstands moderate industrial conditions (e.g., indoor control cabinets, factory auxiliaries) without performance loss |
• Compliance Standards: CE, RoHS, IEC 61131-2, UL 508, CSA C22.2 No.14 |

2. Core Features

• Ultra-Compact Form Factor: 80×100×15mm thin PCB design—fits in space-constrained S800 sub-racks or compact control panels (e.g., machine tool auxiliaries), maximizing storage capacity without 占用 excess rack space.
• Balanced Memory Architecture: 64MB SLC Flash + 16MB ECC RAM—separates long-term configurations (e.g., control logic) from temporary data (e.g., real-time sensor values), optimizing both storage durability and access speed for mid-scale applications.
• Industrial-Grade Reliability: 100,000+ write cycles and 15-year data retention (at 25℃)—ensures long-term stability for infrequently modified logic (e.g., conveyor control programs) and short-term logs, avoiding premature memory failure.
• Basic Data Integrity Tools: CRC-32 checksum validation and static wear leveling—automatically detects corrupted files and extends Flash lifespan, reducing the risk of unplanned downtime from memory errors.
• Seamless S800 Integration: Plugs directly into S800 backplanes via DIN 41612 connector—auto-detects via native protocol, requiring no custom drivers; supports one-click backup/restore of logic/configurations via ABB Control Builder software.
• Cost-Effective Design: FR-4 PCB with Class 2 conformal coating—balances durability and affordability, ideal for non-safety-critical applications (e.g., building HVAC, small process skids) where extreme ruggedness is unnecessary.
• At-A-Glance Diagnostics: Basic fault reporting via S800 bus (e.g., low battery, bad blocks)—enables maintenance teams to quickly identify memory issues without specialized tools, simplifying troubleshooting.

3. Application Fields

• Manufacturing Auxiliaries: Compact memory for secondary systems:
  • Conveyor Control Panels: Stores conveyor logic (64MB Flash) and caches real-time belt speed data (16MB RAM)—48-hour battery backup preserves production counts during brief outages, avoiding line resets.
  • Packaging Machine Sub-systems: Retains 30+ product configurations (SLC Flash) and batch logs—CRC-32 validation ensures no corrupted settings are used, reducing packaging defects.
• Small Process Skids: Mid-scale data storage:
  • Water Treatment Skids: Stores pump control logic and 2-week flow logs—15-year Flash retention ensures long-term configuration stability; compact design fits skid-mounted control cabinets.
  • Chemical Dosing Units: Caches real-time chemical level data (ECC RAM) and stores dosing recipes—simple wear leveling supports daily recipe updates without memory degradation.
• Building Automation: Space-efficient storage:
  • HVAC Zone Controllers: Stores temperature setpoint configurations (Flash) and caches occupancy sensor data (RAM)—ultra-thin design fits narrow mechanical room cabinets; wide temperature range suits unconditioned spaces.
  • Lighting Control Systems: Retains lighting schedule logic and energy usage logs—cost-effective solution for commercial buildings, reducing overall automation infrastructure costs.
• Food & Beverage Small Lines: Practical memory solution:
  • Snack Food Packaging Lines: Manages 20+ product recipes (Flash) and real-time weight data (RAM)—48-hour battery backup preserves data during clean-in-place (CIP) power cycles.
  • Beverage Dispensers: Stores ingredient mixing ratios and sales logs—compact size fits under-counter control boxes; moderate environmental ratings suit indoor retail settings.

4. Precautions

• System Compatibility (Critical): Use only with ABB S800 non-redundant controllers (e.g., DSDON001, DSCL110) and standard S800 backplanes—redundant systems require higher-tier memory modules (e.g., DSMB123); verify via ABB’s DSMB133 compatibility list.
• Installation & Wiring Safety:
  • ESD Protection: Handle only with grounded wrist straps and anti-static packaging—static discharge can damage ECC RAM components; avoid installation in ungrounded work areas.
  • Battery Replacement: Replace the lithium battery (part no. 3HAC028357-001) every 3 years or when low-battery alerts appear—disconnect main power before replacement to avoid data loss; use only ABB-approved batteries.
  • Mounting Torque: Tighten M2.5 mounting screws to 0.3Nm—over-tightening warps the thin PCB; under-tightening causes intermittent backplane connections in vibrating environments (e.g., near motors).

The structure and details of the product：
