ABB DSDX180A 3BSE018297R1 High-Performance Digital Input/Output Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB DSDX180A 3BSE018297R1 High-Performance Digital Input/Output Board Product Data

Product Overview:

The ABB DSDX180A 3BSE018297R1 High-Performance Digital Input/Output Board is a key component in ABB's automation systems. It is designed for efficient processing of digital input and output signals in industrial environments, providing reliable control functionalities. This module supports multiple input and output channels simultaneously and is ideal for applications that require high-speed and high-precision digital signal control. It is widely used in automated production lines, equipment monitoring, process control, and other industrial automation systems.

Key Technical Specifications:

• Input Type: Digital input (dry contact or active signals), supports binary signals

• Output Type: Digital output (relay or binary output)

• Input Channels: Up to 32 digital input channels

• Output Channels: Up to 32 digital output channels

• Operating Voltage: 24V DC

• Operating Temperature Range: -20°C to +60°C

• Storage Temperature Range: -40°C to +85°C

• Protection Class: IP20

• Response Time: <10ms

• Input Signal Voltage Range: Compatible with 24V DC signals

• Output Signal Voltage Range: Supports 24V DC output signals

• Communication Interface: Supports standard industrial communication protocols (e.g., PROFIBUS, Modbus)

• Dimensions: W 120mm x H 130mm x D 80mm

• Weight: Approximately 350g

• Mounting Method: DIN rail mounting

• Max Operating Frequency: Up to 100Hz

• Electromagnetic Interference Protection: Designed for EMI protection to ensure high stability and reliability

Product Advantages and Features:

1. High-Performance Digital Signal Processing: The DSDX180A module utilizes efficient digital signal processing technology to provide precise and stable input and output signal handling, ideal for high-speed production lines and automation equipment.

2. Multi-Channel Input/Output Support: It supports up to 32 digital inputs and 32 digital outputs, handling complex field requirements and enabling multiple control tasks within a single module, increasing system integration.

3. Compatibility with Various Devices: Supports dry contacts, relay outputs, and other signal types, making it compatible with a wide range of industrial devices and applications.

4. High Reliability and Stability: Built to industrial standards, the module offers excellent resistance to electromagnetic interference and is designed for long-term stable operation, ensuring continuous performance in demanding environments.

5. Fast Response Time: With a response time of less than 10ms, the DSDX180A is suitable for real-time control and monitoring, essential for high-speed signal handling.

6. Modular Design: The module is DIN rail-mounted, making installation and maintenance quick and easy. The modular design allows for convenient future expansion and upgrades.

7. Wide Application Compatibility: It supports common industrial communication protocols such as PROFIBUS and Modbus, allowing for seamless integration with other automation control systems and increasing system flexibility.

Application Areas:

1. Automated Production Lines: In automated production lines, the DSDX180A can control equipment start/stop, alarms, and other operations, ensuring efficient and stable production processes.

2. Mechanical Equipment Control: It is used for controlling switches and monitoring the status of mechanical equipment, ensuring optimal performance and reducing downtime.

3. Process Control Systems: In industries like chemicals, oil, and food, the DSDX180A can monitor and control multiple input/output channels, ensuring accurate and efficient production control.

4. Building Automation and Smart Buildings: It is used in building automation systems for controlling devices like lighting, HVAC systems, elevators, and other facilities.

5. Energy Management and Monitoring: In power and energy sectors, the DSDX180A can control and monitor equipment remotely, allowing for real-time control and optimization of energy consumption.

6. Traffic Control Systems: It is used for controlling traffic signals and monitoring traffic flow in transportation management systems, improving automation and operational efficiency.

Precautions:

1. Power Stability: Ensure a stable 24V DC power supply for the module. Power fluctuations may lead to performance degradation or system malfunction.

2. Environmental Temperature: Ensure the module operates within the temperature range of -20°C to +60°C to avoid performance issues.

3. Wiring Considerations: Ensure correct wiring of input/output signals to avoid errors or short circuits, ensuring stable signal transmission.

4. Electromagnetic Interference Protection: While the module is designed with EMI protection, additional shielding may be required in high-EMI environments to ensure stable operation.

5. Regular Maintenance and Inspection: Periodically inspect the module's status, check connections, and calibrate if necessary to ensure long-term accurate performance.

The structure and details of the product：
