ABB DSDO115A 3BSE018298R1 Digital Output Module

Introduction

The ABB DSDO115A 3BSE018298R1 is a digital output module designed for ABB Symphony Plus, AC 800M, and 800xA control systems. It converts logical signals from the controller into field-level switching signals to drive actuators such as relays, contactors, indicator lights, and valve coils. With high driving capability, fast response, and strong noise immunity, it plays a key role in process automation and industrial control systems.

Technical Specifications

• Model: DSDO115A

• Part Number: 3BSE018298R1

• Type: Digital Output Module

• Channels: 16 digital outputs

• Output Voltage: 24 V DC

• Output Type: Transistor (with short-circuit and current limit protection)

• Max Current per Channel: 0.5 A (typical)

• Total Module Current: Max 8 A

• Isolation: Optical isolation between channels and system bus

• Response Time: < 2 ms

• Power Supply: 24 V DC

• Indicators: Per-channel LED for output status; power and fault indicators

• Operating Temperature: 0℃ to +55℃

• Storage Temperature: -40℃ to +70℃

• Protection Class: IP20 (cabinet installation required)

• Mounting: DIN rail or cabinet installation

• Certifications: CE, UL, RoHS

Features and Benefits

1. High Driving Capability

   • Up to 0.5 A per channel, capable of directly driving relays, lamps, and low-power solenoids.

2. Fast Response

   • Response time less than 2 ms, ideal for real-time applications.

3. Channel Status Indication

   • Individual LEDs per channel simplify monitoring and troubleshooting.

4. Reliable Protection

   • Built-in overcurrent and short-circuit protection enhances system safety.

5. Modular Integration

   • Works seamlessly with DSDI digital input modules and other ABB I/O units for scalable systems.

6. Easy Maintenance

   • Plug-in design for quick replacement and reduced downtime.

Applications

• Process Automation: Actuator control in oil & gas, chemical, power, and metallurgy industries.

• Power Plant Control: Switch control for valves, pumps, and heaters.

• Manufacturing Automation: Output control for assembly lines, packaging systems, and machinery.

• Water Treatment Plants: Control of pumps, valves, and aeration equipment.

• Building Automation: Lighting, alarm, and ventilation systems.

Installation & Maintenance Notes

1. Wiring: Ensure current loads per channel remain within limits.

2. Power Supply: Provide a stable 24 VDC supply to prevent fluctuations.

3. Installation Environment: Install in control cabinets to avoid humidity, dust, or corrosive gases.

4. Cooling: Maintain proper ventilation to prevent overheating.

5. Routine Inspection: Use LED indicators to monitor channel status.

6. System Compatibility: Verify compatibility with AC 800M or 800xA systems.
