ABB DSDI 150 Pulse Encoder Input Unit

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB DSDI 150 is a high-performance Pulse Encoder Input Unit designed for ABB PLC systems (such as AC500 and Advant). It is specifically engineered to receive and process pulses from rotary encoders, incremental encoders, or optical encoders, enabling precise speed, position, and rotation measurement.

DSDI 150 features fast response, interference immunity, and high reliability, making it an essential module for precise measurement and control in industrial automation.

2. Technical Specifications

• Model: DSDI 150

• Product Type: Pulse Encoder Input Unit

• Channels: 4 channels (expandable)

• Input Signal Type: Incremental encoder pulses, TTL/HTL signals

• Power Supply: 24 VDC

• Maximum Input Frequency: 100 kHz

• Isolation: Optical isolation

• Response Time: ≤10 µs

• Counting Modes: Single-direction and bi-directional counting

• Interface: Backplane / bus connection

• Operating Temperature: –20°C to +60°C

• Storage Temperature: –40°C to +85°C

• Protection Class: IP20

• Mounting: Rack / DIN rail

• Applicable Systems: ABB AC500, Advant PLC systems

3. Features & Advantages

• High-speed pulse signal processing up to 100 kHz

• Accurate counting for position, speed, and rotation measurement

• Optical isolation design prevents signal interference

• Multi-channel support for multi-axis and complex process systems

• Modular design for easy installation and maintenance

• Seamless compatibility with ABB AC500 and Advant PLC systems

4. Application Areas

• Industrial automation and production line control

• Motor speed and position monitoring

• Encoder signal acquisition and multi-axis control systems

• Packaging machinery and counting systems

• Conveyor and robotics control

• Water treatment and municipal automation

• Chemical, metallurgical, mining, and energy automation systems

5. Precautions

1. Ensure proper compatibility with the backplane or bus before installation.

2. Disconnect power during wiring to prevent short circuits or misoperation.

3. Encoder signal inputs must comply with module voltage and frequency specifications (TTL/HTL).

4. Avoid wiring in high-interference, high-humidity, or dusty environments; use shielding and grounding if necessary.

5. Regularly check terminal connections and encoder signal stability to ensure measurement accuracy.

6. Do not exceed the module’s maximum input frequency to prevent counting errors or device damage.

The structure and details of the product：
