ABB DSCA190V 57310001-PK Communication Module

1. Key Parameters

• Product Model: DSCA190V 57310001-PK
• Product Series: ABB S800 I/O EtherNet/IP Communication Modules (ODVA-Compliant Integration)
• Core Function: Enables bidirectional EtherNet/IP communication between S800 I/O modules and EtherNet/IP masters; supports ODVA-compliant CIP (Common Industrial Protocol); provides dual-Ethernet redundancy; monitors data integrity; offers surge protection and protocol-specific diagnostics
• Communication & Protocol Specifications:

  Parameter	Details	Performance Metrics
  Supported Protocols	- Primary: EtherNet/IP (ODVA-compliant, CIP v4) - Protocol Features: Explicit messaging (configuration), implicit messaging (real-time I/O) - Role: EtherNet/IP adapter (slave) with support for up to 8 master connections	Seamless integration with Rockwell Automation systems (e.g., ControlLogix, FactoryTalk) without custom drivers
  Data Transmission Performance	- Data Rate: 10/100Mbps (auto-sensing, full-duplex) - Real-Time Latency: <30ms (implicit messaging for I/O data) - Maximum I/O Data Size: 1024 bytes (input) / 1024 bytes (output) - Connection Count: 8 concurrent EtherNet/IP master connections	Fast implicit messaging ensures real-time control (e.g., 32 S800 I/O points updated every 30ms) for dynamic processes

• Redundancy & Protection Specifications:

  Parameter	Details	Performance Metrics
  Network Redundancy	- Redundancy Protocol: EtherNet/IP DLR (Device Level Ring) - Recovery Time: <10ms (DLR ring fault recovery) - Port Configuration: 2× RJ45 Ethernet ports (for DLR ring topology)	DLR redundancy ensures 99.999% network availability—critical for 24/7 production lines and safety-critical processes
  Electrical Protection	- Surge Protection: ±25kV ESD (IEC 61000-4-2); ±12kV surge (IEC 61000-4-5) on Ethernet ports - Isolation: 2.5kV AC between Ethernet ports, S800 backplane, and chassis - EMC Compliance: EN 61326-3-1 (industrial noise immunity, Class A)	Surge protection withstands lightning-induced transients and motor startup spikes; isolation eliminates ground loops in distributed networks

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 100mm (W) × 160mm (H) × 210mm (D) (S800 module form factor) - Mounting Type: ABB DSBB102/DSBB107/DSBB175 bus backplanes (35mm DIN rail compatible via adapter) - Housing Material: EMI-shielded ABS plastic (UL 94 V0, flame-retardant) with copper grounding pads - Weight: Approximately 650g - LED Indicators: 8 LEDs (power, 2× Ethernet link, 2× DLR status, 2× fault, 1× CIP communication)	Compact design fits standard S800 racks; EMI shielding reduces noise pickup from motors/VFDs; DLR status LEDs provide at-a-glance redundancy health
  Environmental Ratings	- Operating Temperature Range: -25℃~+70℃ (-13℉~158℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6) - Shock Resistance: 20g (11ms half-sine, IEC 60068-2-27)	Withstands extreme industrial conditions (e.g., outdoor utility cabinets, chemical plant switchrooms) without performance degradation

• Compliance Standards: CE, RoHS, IEC 61131-2, UL 508, CSA C22.2 No.14, EN 61326-3-1 (EMC), ODVA EtherNet/IP Certification, ATEX II 3G/3D (hazardous area compatible with approval)

2. Key Features

• ODVA-Compliant EtherNet/IP Integration: Fully compliant with EtherNet/IP and CIP standards—enables plug-and-play integration with Rockwell Automation controllers (e.g., ControlLogix, CompactLogix) and third-party EtherNet/IP devices, eliminating the need for custom interface software and reducing engineering time by 40%.
• Device Level Ring (DLR) Redundancy: Dual Ethernet ports support DLR topology with <10ms fault recovery—prevents network downtime during cable cuts, switch failures, or maintenance, ensuring uninterrupted I/O data flow for critical processes (e.g., chemical batch control).
• Robust Electrical Protection: ±25kV ESD and ±12kV surge protection on Ethernet ports—withstands voltage transients from lightning, motor startups, or cable faults, ensuring reliable operation in outdoor or industrial environments (e.g., oil well monitoring, wastewater plants).
• 2.5kV Multi-Level Isolation: Electrical isolation between Ethernet ports, S800 backplane, and chassis—eliminates ground loops in distributed installations (e.g., a factory with multiple power distribution panels) and protects sensitive S800 I/O modules from voltage spikes.
• Dual Messaging Modes: Supports both implicit (real-time I/O) and explicit (configuration/diagnostics) messaging—implicit messaging delivers fast, cyclic I/O updates for control tasks, while explicit messaging enables offline configuration and fault troubleshooting without disrupting production.
• Real-Time Diagnostics: Monitors DLR ring status, CIP communication errors, surge events, and module health—provides detailed fault codes (e.g., "DLR ring break," "CIP connection timeout") via LEDs and EtherNet/IP, allowing technicians to identify and resolve issues in minutes.
• Seamless S800 Integration: Auto-detects connected S800 I/O modules (analog, digital, specialty) and maps their signals to EtherNet/IP I/O data—requires no manual configuration of I/O points, reducing commissioning time and minimizing configuration errors.
• Wide Operating Range: -25℃~+70℃ temperature tolerance—operates reliably in unconditioned cabinets (e.g., remote pump stations, outdoor substations) without additional cooling/heating, expanding deployment flexibility.

3. Application Fields

• Cross-Vendor Automation Integration: Bridging ABB S800 I/O with EtherNet/IP systems:
  • Automotive Manufacturing: Connects S800 I/O modules (robot position sensors, weld gun current monitors) to a Rockwell ControlLogix PLC—DLR redundancy ensures no downtime during production line maintenance, while implicit messaging delivers real-time control of assembly robots.
  • Food & Beverage Processing: Links S800 temperature (PT100) and digital I/O (valve status) to a FactoryTalk SCADA system—EtherNet/IP compliance integrates with existing Rockwell-based batch control, ensuring consistent product quality and FDA compliance.
• Process Control & Oil & Gas: Supporting critical fluid and energy processes:
  • Chemical Plants: Connects S800 analog modules (reactor pressure, reagent flow) to an EtherNet/IP DCS—DLR redundancy prevents communication loss during cable faults, while surge protection withstands electrical transients from mixing motors.
  • Onshore Oil Wells: Integrates S800 pressure/flow modules across 32 wellheads to a Rockwell PLC—wide temperature range and surge protection ensure operation in desert environments, while isolation eliminates ground loops between well pads.
• Water & Wastewater Infrastructure: Managing distributed pumping and treatment:
  • Municipal Water Treatment: Connects S800 I/O modules (pump pressure, chemical dosing levels) to an EtherNet/IP SCADA—DLR ring topology ensures no data loss from remote pump stations, while explicit messaging enables remote configuration of I/O points without site visits.
  • Flood Control Systems: Links S800 valve position and level sensors to a ControlLogix controller—surge protection withstands lightning strikes, while real-time diagnostics alert operators to faulty sensors before floodgate failures.
• Manufacturing Legacy Modernization: Upgrading existing systems with S800 I/O:
  • Electronics Assembly: Adds S800 precision analog modules (PCB test voltage, component placement) to a legacy EtherNet/IP-based line—seamless integration extends the life of existing Rockwell controllers, avoiding costly system replacement.
  • Packaging Machinery: Connects S800 digital I/O (sealing bar status, film tension) to a CompactLogix PLC—implicit messaging delivers fast control of packaging cycles, reducing material waste and improving throughput.
