ABB DPMP-EXT 3AXD50000010763 Panel door mounting kit

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

The ABB DPMP‑EXT (part number 3AXD50000010763) is a panel door mounting kit designed for ABB drives / inverters. It allows the control panel / operator interface of a drive to be mounted securely on the door of an electrical cabinet. This kit includes two main components: DPMP‑02 and CDPI‑01, providing a standardized and reliable method to mount the drive interface to a door.

The kit is intended for one drive, containing DPMP‑02 and CDPI‑01.

Detailed Specifications / Components

Advantages & Features

1. Convenient panel-to-door mounting
   Allows the drive’s control panel to be mounted on the cabinet door, improving usability and accessibility.

2. Standardized components
   Uses standard DPMP‑02 and CDPI‑01 parts, making replacement and maintenance easier.

3. Reduced cabinet modification
   Minimizes the need for custom cutting or alteration of the door panel.

4. Stable mechanical support
   Engineered to support the weight of the panel with proper rigidity and durability.

5. Accessible control interface
   Mounting on door makes the interface readily viewable and operable without opening enclosure.

6. High compatibility
   Designed to interface with ABB drive panels, ensuring broad applicability across models.

Typical Applications

• Mounting ABB drive / inverter control panels on cabinet doors

• In control / distribution cabinets where interfaces are needed on doors

• Industrial automation systems needing clean and accessible panel layout

• Cabinet systems where door-mounted operator panels ease maintenance and operations

• Electrical enclosures where aesthetic and standardization of user interface are needed

Installation / Usage Notes

1. Hole / cutout alignment
   Before installation, verify the hole layout and dimensions match those of the control panel and DPMP‑EXT kit.

2. Door structural integrity
   Ensure the door panel is thick and rigid enough to support the weight and operating forces without deformation.

3. Sealing and dust protection
   Provide sealing or gasket around the mounted interface to prevent dust, moisture ingress at the door panel.

4. Cable routing & slack
   Leave appropriate slack in cables feeding the panel, and route them to avoid chafing or interference with door movement.

5. Proper fastening & anti‑loosen measures
   Use correct torque for screws / fasteners, and include locking nuts or washers to prevent loosening over time.

6. Compatibility check
   Confirm that the drive control panel and kit are physically and electronically compatible before installation.

7. Verify operation after install
   After mounting, test panel operation, confirm viewing angle, check for interference or binding between panel and door.
