ABB DP30C2P-2 Contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DP30C2P-2 is a compact AC contactor designed for small motor control, lighting, and heating loads. With its compact size, reliable operation, and high-frequency switching capability, it is suitable for industrial automation, building electrical systems, and light industrial equipment control. The DP30C2P-2 is part of ABB’s modular contactor series, making it easy to integrate into control panels and switchboards.

2. Technical Specifications

• Model: DP30C2P-2

• Product Type: AC Contactor

• Rated Current: 30 A

• Rated Operational Voltage: AC 400 V

• Coil Voltage: 220 V AC / 50 Hz (options: 110 V, 380 V, etc.)

• Number of Poles: 2 main contacts + 2 auxiliary contacts (NO + NC)

• Mechanical Life: ≥ 10,000,000 operations

• Electrical Life: ≥ 100,000 operations (at rated load)

• Insulation Class: F

• Mounting: DIN rail

• Protection Class: IP20

• Operating Temperature: -25 ℃ to +55 ℃

• Standards Compliance: IEC 60947-4-1, GB/T 14048.4

• Features: Compact, reliable, high-frequency switching, modular design

3. Key Advantages & Features

• Compact Design – Saves space for panel and modular installations.

• Reliable Operation – High-quality electromagnetic coil ensures sensitive and interference-resistant operation.

• Long Lifespan – Mechanical and electrical durability for high-frequency operations.

• Flexible Auxiliary Contacts – Supports signaling, interlocks, and extended control logic.

• Multiple Coil Voltages – Flexible adaptation to different control supply systems.

• Standards Compliant – Meets IEC 60947-4-1 industrial standards.

4. Typical Applications

• Small industrial motor control (pumps, fans, compressors)

• Automation production lines and equipment control

• Building lighting and heating load control

• Modular control in panels and switchboards

• Remote signaling and interlocks

• Light industrial and maintenance isolation

5. Installation & Usage Notes

• Match Load and Current – Ensure contactor rating matches the load to avoid overload or nuisance trips.

• Match Coil Voltage – Control supply voltage must match the coil rating.

• Proper Installation & Wiring – Connect main and auxiliary contacts according to the control circuit design.

• Avoid Harsh Environments – Minimize exposure to high humidity, temperature, or corrosive environments; use protective measures if necessary.

• Periodic Inspection – Check contacts, auxiliary contacts, and coil status for reliable long-term operation.
