ABB DI803 8-channel 230 V AC/DC digital input module

​ABB DI803 8-channel 230 V AC/DC digital input module

5. 1. Product Description​
   The ABB DI803 is a high-adaptability 8-channel digital input module developed for industrial automation scenarios, supporting dual input voltage standards of 230 V AC and 230 V DC. It is dedicated to collecting digital signals from on-site devices such as high-voltage industrial switches, temperature control relays, and emergency stop contacts, then converting these signals into standardized digital data that can be efficiently identified and processed by upper controllers (e.g., ABB AC 800M DCS). Equipped with high-voltage resistance and strong anti-interference capabilities, the module ensures stable and accurate transmission of on-site status signals, providing a reliable hardware guarantee for the monitoring and control of medium-to-high voltage industrial processes.​
   2. Detailed Parameters​
   ​

   Parameter Category​	Specifications​
   Input Channels​	8 channels (isolated per channel)​
   Input Signal Type​	230 V AC / 230 V DC digital input (dual-voltage compatible)​
   Input Voltage Range (AC)​	184 - 276 V AC (50/60 Hz)​
   Input Voltage Range (DC)​	184 - 276 V DC​
   Input Current​	AC: Typical 4 mA (at 230 V AC); DC: Typical 3.5 mA (at 230 V DC)​
   Isolation​	Channel-to-channel: 2500 V AC (1 minute); Channel-to-backplane: 2500 V AC (1 minute)​
   Response Time​	≤ 8 ms (for AC signal transition); ≤ 3 ms (for DC signal transition)​
   Operating Temperature​	-40°C to +70°C​
   Dimensions (W×H×D)​	48.3 × 100 × 150 mm​
   Mounting Method​	DIN rail mounting (compatible with standard 35 mm DIN rails)​







   ​
   3. Advantages & Features​
   1. High-Voltage Dual Compatibility: Supports 230 V AC/DC dual voltage inputs, suitable for industrial sites with medium-to-high voltage power systems, avoiding the need for voltage conversion accessories and simplifying system configuration.​
   2. Enhanced Isolation Performance: 2500 V AC independent channel isolation, effectively resisting high-voltage interference and leakage risks, ensuring safe operation of both the module and the upper system.​
   3. Wide Voltage Tolerance: ±20% voltage tolerance for AC/DC inputs, adapting to on-site power supply fluctuations (e.g., voltage dips or surges) and maintaining stable signal collection.​
   4. Reliable Signal Capture: Optimized response time (3-8 ms) balances speed and stability, meeting the monitoring requirements of high-voltage equipment such as industrial pumps, fans, and high-voltage valves.​
   5. Harsh Environment Adaptability: Withstands -40°C to +70°C wide temperature range and strong electromagnetic interference (EMI), suitable for heavy industry, outdoor infrastructure, and other harsh application scenarios.​
   4. Application Fields​
   • Heavy Industry (Mining/Cement): Monitoring the on/off status of high-voltage motor control switches, crusher emergency stops, and cement kiln auxiliary device contacts.​
   • Power Transmission & Distribution: Detecting the status of substation auxiliary switches, transformer temperature protection relays, and power distribution cabinet alarm contacts.​
   • Oil & Gas (Upstream Exploration): Collecting signals from offshore platform high-voltage pump switches, pipeline pressure alarm contacts, and wellhead control valve status sensors.​
   • Industrial Infrastructure (Large Factories): Monitoring the operation status of factory central air conditioning high-voltage compressors, boiler feed water pump switches, and workshop power distribution branch contacts.​
   5. Precautions​
   1. Strictly confirm the input voltage type (AC/DC) and range before wiring; do not connect voltages exceeding 276 V AC/DC to prevent module burnout or insulation damage.​
   2. When installing in high-voltage environments (e.g., substations), maintain a safe distance (≥10 cm) from high-voltage cables to avoid electromagnetic interference affecting signal accuracy.​
   3. For AC input signals, ensure the power frequency (50/60 Hz) matches the module’s design; frequency mismatch may cause signal misjudgment or response delay.​
   4. Use wires with insulation strength ≥2500 V AC for wiring, and ensure proper grounding of the module’s backplane to prevent electric shock or interference.​
   5. Regularly inspect the module’s terminal connections and insulation status (especially in humid or dusty environments); clean terminals and replace aging wires in a timely manner to avoid poor contact or short circuits.​
