ABB DCF503B0050 Field Excitation Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DCF503B0050 Field Excitation Module is a field excitation control module for ABB generators and industrial automation systems.
It provides stable excitation current for synchronous generators or motors, ensuring stable operation and precise voltage and power control.
The module supports closed-loop excitation control and fast response to load changes, making it a key component in power systems and industrial drive control.

2. Main Technical Specifications (Typical)

• Model: DCF503B0050

• Product Type: Field Excitation Module

• Rated Excitation Voltage: DC 0–150 V (configurable depending on application)

• Rated Excitation Current: 0–5 A

• Input Signal: Analog input (0–10 V / 4–20 mA selectable)

• Control Mode: Closed-loop voltage or current control

• Response Time: Typically <10 ms

• Supply Voltage: DC 24 V

• Mounting: DIN rail or rack installation

• Operating Temperature Range: -25 ℃ to +60 ℃

• System Compatibility: ABB generator control systems and industrial drive systems

3. Key Advantages and Features

1. Stable and Reliable Excitation Control

   • Precisely regulates excitation current

   • Ensures stable synchronous generator operation

2. Fast Load Response

   • Closed-loop control provides rapid voltage adjustment

   • Enhances system dynamic performance

3. Industrial-Grade Design

   • Wide operating temperature, vibration and interference resistant

   • High reliability for complex industrial environments

4. Modular Installation

   • DIN rail or rack-mounted for easy maintenance and replacement

   • Supports multi-module expansion and system integration

5. High Compatibility

   • Seamlessly integrates with ABB generator excitation and industrial drive control systems

4. Typical Applications

• Synchronous generator excitation control

• Industrial generator and backup power systems

• Power system automation control

• Large motor drive excitation

• Industrial automation and drive control systems

• Hydroelectric, thermal, and renewable power plants

5. Installation and Maintenance Notes

1. Verify Input and Output Parameters

   • Excitation voltage, current, and control signals must match generator or motor specifications

2. Power-Off Before Installation

   • Disconnect power before installing or removing the module

3. Proper Wiring

   • Securely connect excitation and signal wires

   • Avoid routing signal wires parallel to high-voltage lines

4. Environmental Conditions

   • Avoid high temperature, humidity, and corrosive environments

   • Ensure proper ventilation in the cabinet

5. Periodic Inspection and Maintenance

   • Check module status and output current

   • Ensure long-term stable system operation
