ABB DC501-CS31-AD Digital/Analog Input/Output Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

•

• 1. Product Overview

  The ABB DC501-CS31-AD is a high-performance Digital/Analog Input/Output Module designed for ABB control systems or Distributed Control Systems (DCS). It collects and outputs both digital and analog signals, enabling monitoring and control of switches, sensors, actuators, and other field devices. Compact design with DIN rail mounting makes it ideal for industrial automation and building management applications.

  ---

  2. Technical Specifications

  Parameter	Specification
  Model	DC501-CS31-AD
  Type	Digital/Analog I/O Module
  Digital Inputs	16 DI (24 V DC, dry contact or active signal)
  Analog Inputs	8 AI (0–10 V / 4–20 mA, configurable)
  Analog Outputs	4 AO (0–10 V / 4–20 mA, configurable)
  Communication Interface	ABB DCS Bus (or compatible protocol, e.g., Modbus optional)
  Supply Voltage	24 V DC ±10%
  Power Consumption	< 10 W
  Response Time	< 5 ms (digital input)
  Measurement Accuracy	±0.5% (analog I/O)
  Mounting	DIN rail (35 mm)
  Operating Temperature	-25 ℃ ~ +55 ℃
  Protection Rating	IP20
  Standards	IEC/EN 61131-2 / IEC/EN 61010-1

  ---

  3. Key Features and Benefits

  • Multi-function integration: Supports digital and analog I/O in a single module, simplifying wiring.

  • High precision & fast response: Accurate analog measurements and rapid digital response.

  • Modular design: Easy expansion and replacement for various control systems.

  • High reliability: Industrial-grade design with strong interference resistance.

  • Easy installation: DIN rail mounting for convenient panel layout.

  ---

  4. Typical Applications

  • Industrial automation control systems

  • Distributed Control Systems (DCS)

  • Building automation and monitoring systems

  • Sensor and actuator signal acquisition and control

  • Machinery and production line automation

  • Energy management and power distribution monitoring

  ---

  5. Installation & Usage Notes

  1. Power matching: Ensure module supply voltage matches system (24 V DC).

  2. Wiring: Follow wiring diagram for digital/analog I/O to avoid misconnection or short circuits.

  3. Environmental conditions: Avoid high temperature, humidity, corrosive gases, and strong EMI.

  4. Regular inspection: Check terminal connections and module status to ensure reliable operation.

  5. Module expansion: When using multiple modules, ensure bus addressing and communication protocol settings are correct.

•
•

The structure and details of the product：

 Please make an inquiry for more models：
