ABB DATX110 3ASC25H209 Circuit Board Analog I/O Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• 1. Product Overview

  The ABB DATX110 (3ASC25H209) Analog I/O Module is a key component used in ABB Distributed Control Systems (DCS) such as AC800M, Advant, and Freelance. It provides reliable analog signal acquisition and output control between field devices and the main controller.
  Featuring high accuracy, strong noise immunity, and galvanic isolation, the DATX110 ensures precise process data handling and stable system operation under demanding industrial conditions.

  ---

  2. Technical Specifications

  Item	Specification
  Model	DATX110
  Order Code	3ASC25H209
  Type	Analog Input/Output Module
  System Compatibility	ABB DCS / AC800M / Advant Series
  Analog Inputs	8 channels
  Analog Outputs	8 channels
  Input Signal Type	Current (0–20 mA / 4–20 mA), Voltage (0–10 V)
  Output Signal Type	Current (0–20 mA / 4–20 mA)
  Resolution	12-bit (up to 0.05% accuracy)
  Isolation	Optical isolation between field and system bus
  Power Supply	24 V DC
  Power Consumption	≤ 6 W
  Communication Interface	System Bus / I/O Bus
  Response Time	≤ 10 ms
  Operating Temperature	0°C to +55°C
  Storage Temperature	-25°C to +70°C
  Protection Class	IP20
  Dimensions	Approx. 150 mm × 100 mm × 40 mm
  Weight	Approx. 0.3 kg
  Standards Compliance	IEC 61131, IEC 61010, EN 61326

  ---

  3. Advantages & Features

  • High Precision Sampling – 12-bit resolution ensures accurate process data acquisition.

  • Strong Noise Immunity – Optical isolation and filtering for stable communication.

  • Flexible I/O Options – Supports both current and voltage signal formats.

  • Fast Response – Suitable for real-time control applications.

  • Modular Design – Easy installation and expansion on ABB I/O racks.

  • High Reliability – Designed for harsh industrial environments.

  ---

  4. Application Fields

  • Process automation in chemical, metallurgy, and paper industries

  • Power generation and substation control systems

  • Oil and gas process monitoring

  • Robotics and smart manufacturing control

  • Building and energy management systems

  ---

  5. Precautions

  1. Always disconnect power before installation or maintenance.

  2. Use shielded cables and proper grounding to prevent signal interference.

  3. Verify I/O configuration before wiring.

  4. Avoid installation in corrosive or humid environments.

  5. Regularly inspect terminal connections and communication status.

•
•

The structure and details of the product：

Please make an inquiry for more models
