ABB DAI05 analog input module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB DAI05 Analog Input Module Product Overview

Introduction:

The ABB DAI05 Analog Input Module is an essential component for industrial automation systems, designed to interface with analog sensors and provide real-time data to a central control system. This module is part of ABB's modular automation systems and is widely used in applications requiring the monitoring and processing of analog signals such as temperature, pressure, flow, and other continuous measurements. The DAI05 module ensures accurate and reliable data acquisition, making it an essential tool for applications in industries such as manufacturing, energy, and process control.

Key Specifications:

• Module Type: Analog Input Module

• Input Channels: 8 analog inputs (with selectable input ranges)

• Input Signal Type:

  • Voltage Input: 0–10V, ±10V

  • Current Input: 4–20 mA (with or without HART communication)

  • Resistance: 0–5000 Ω (for temperature or pressure sensors)

• Input Resolution: 16-bit analog-to-digital conversion

• Power Supply: Typically 24V DC (can vary depending on the configuration)

• Mounting: DIN rail mountable (for ease of installation in control cabinets)

• Communication:

  • Modbus RTU (RS-485)

  • Modbus TCP for communication with a central control system

• Operating Temperature: -10°C to +60°C

• Storage Temperature: -40°C to +85°C

• Protection Rating: IP20 (indoor use)

• Dimensions: Approx. 140mm x 90mm x 120mm (subject to configuration)

• Weight: Approx. 0.35 kg (subject to configuration)

• Certification: CE, UL, RoHS compliant

Features and Benefits:

1. High-Precision Analog Inputs:

   • The DAI05 module supports both voltage and current input types, allowing it to interface with a variety of analog sensors and devices. It provides 16-bit resolution, ensuring high precision in signal conversion and accurate data representation.

2. Wide Input Range Compatibility:

   • With configurable input ranges, the DAI05 can accept a wide variety of sensor outputs, including 0–10V, ±10V, and 4–20 mA signals. This flexibility makes it suitable for diverse applications that require different signal types.

3. Real-Time Data Acquisition:

   • The DAI05 module is designed for real-time data acquisition. It continuously monitors analog signals and transmits the processed data to the control system, ensuring timely and accurate decision-making in critical processes.

4. Communication Flexibility:

   • The module supports Modbus RTU and Modbus TCP protocols for easy integration into various control systems. It can connect to a central system over RS-485 or Ethernet networks, providing seamless communication with other devices and systems.

5. Modular and Expandable:

   • The DAI05 module is part of a modular system, allowing easy integration with other ABB modules for expanded I/O capabilities. Users can configure and expand their system to meet evolving automation needs.

6. Rugged and Reliable:

   • The DAI05 is built to withstand challenging industrial environments. With an IP20 rating, it is designed to be mounted inside control cabinets, protecting the module from dust and physical damage while ensuring reliable operation in demanding conditions.

7. Space-Saving Design:

   • The DAI05 module is designed to be compact and DIN rail mountable, ensuring efficient use of space in control cabinets or enclosures. This is ideal for systems where space is limited and a high density of I/O modules is required.

8. Diagnostic and Fault Indicators:

   • Built-in diagnostic LEDs indicate the status of the module, including power, communication, and input signal health. This makes it easier for operators to monitor system health and troubleshoot any issues promptly.

9. Wide Operating Temperature Range:

   • The DAI05 module can operate in environments with a wide temperature range of -10°C to +60°C, making it suitable for both indoor and outdoor applications, as well as in environments with varying temperature conditions.

Applications:

1. Industrial Automation:

   • The DAI05 module is used in manufacturing and automation processes where continuous monitoring and control of variables like temperature, pressure, and flow are critical. It allows for the collection of real-time data from sensors, providing accurate process feedback.

2. Process Control:

   • In industries such as chemicals, petrochemicals, pharmaceuticals, and food processing, the DAI05 module helps regulate and monitor important process parameters such as liquid levels, temperatures, and pressures. This ensures compliance with industry standards and improves process efficiency.

3. Energy and Utilities:

   • The DAI05 is used in energy management systems for monitoring and controlling critical parameters such as voltage, current, and energy consumption in power plants, electrical grids, and distribution systems. It ensures reliable operation and enhances the efficiency of energy distribution networks.

4. Building Automation Systems (BMS):

   • The DAI05 module is ideal for building management systems where it can interface with sensors that monitor HVAC systems, lighting, and environmental conditions. It provides real-time data for effective energy management and system optimization.

5. Water and Wastewater Treatment:

   • In water treatment facilities, the DAI05 is used to monitor various parameters such as flow rates, chemical concentrations, and water quality. It plays a key role in maintaining optimal conditions and ensuring compliance with environmental regulations.

6. Environmental Monitoring:

   • The DAI05 module is used in environmental monitoring systems to measure parameters such as air quality, temperature, humidity, and pollutant levels. It provides continuous data for environmental control and regulation.

7. SCADA Systems:

   • The DAI05 module integrates with SCADA systems for remote monitoring and control of industrial processes. It collects analog data from sensors and transmits it to the SCADA system for centralized monitoring and decision-making.

8. Automated Packaging:

   • The DAI05 is used in automated packaging lines for monitoring parameters such as pressure in sealing machines, temperature in heating units, and flow rates in material handling systems. It ensures smooth and efficient operation of the production line.

9. Test and Measurement:

   • In laboratory and testing environments, the DAI05 module interfaces with test equipment and sensors to collect data on various physical parameters. This data is used for research, analysis, and quality control.

Installation and Maintenance Considerations:

1. Power Supply Configuration:

   • Ensure that the DAI05 module is connected to a stable 24V DC power supply. A reliable power source is essential for maintaining the module’s performance and ensuring continuous operation.

2. Signal Grounding:

   • Proper grounding of the input signals is important to prevent electrical interference and to ensure accurate data acquisition. Follow best practices for grounding to maintain signal integrity and module accuracy.

3. Proper Ventilation:

   • The module should be installed in a well-ventilated area to prevent overheating. Ensure adequate airflow around the module, especially in control cabinets with multiple components.

4. Module Slot Configuration:

   • Ensure that the DAI05 module is installed in the correct slot or mounting configuration in the control rack. Verify that it is properly connected to the system’s communication network for seamless data transmission.

5. Cable Management:

   • Organize cables and wiring to prevent interference and to avoid signal degradation. Use appropriate connectors and ensure that the input signals are routed to the correct terminals.

6. Diagnostic Monitoring:

   • Regularly check the diagnostic LEDs on the module to monitor its health. The LEDs will indicate power, communication status, and any faults with the input signals. Address any issues promptly to minimize downtime.

7. Environmental Protection:

   • The DAI05 module has an IP20 rating, which means it is suitable for indoor use. Ensure that the module is protected from moisture, dust, and other contaminants that could affect its operation. If used in harsh environments, consider installing it in an enclosure with higher protection ratings.
