ABB CVC750BE101 3BHE009681R0101 IGCT module

ABB CVC750BE101 3BHE009681R0101 IGCT Module

Overview:

The ABB CVC750BE101 3BHE009681R0101 IGCT Module is a high-performance power module designed for industrial drives, renewable energy systems, and high-power conversion applications. Utilizing IGCT (Integrated Gate Commutated Thyristor) technology, it offers superior efficiency, fast switching speeds, and robust protection features for handling high currents and voltages in demanding environments.

Specifications:

• Model: CVC750BE101 3BHE009681R0101

• Power Rating: 750A, 1700V

• Switching Frequency: Up to 20 kHz

• Voltage Rating: 1700V (Maximum)

• Current Rating: 750A (Continuous)

• Temperature Range: -40°C to +85°C

• Enclosure: IP20

• Weight: Approx. 4.0 kg

• Cooling: Forced air or liquid cooling

• Certifications: CE, UL, RoHS compliant

Features:

• High Efficiency and Low Losses

• Fast Switching Performance (Up to 20 kHz)

• Robust and Durable Design (IP20)

• Advanced Protection Features (Overcurrent, Overvoltage, Thermal)

• Wide Operating Temperature Range (-40°C to +85°C)

• Compact Design for Easy Integration

Applications:

• Industrial Drives

• Renewable Energy Systems (Wind, Solar)

• High-Power Converters

• Rail and Transportation Systems

• Heavy Industry and Manufacturing

• HVDC Transmission Systems

• Uninterruptible Power Supplies (UPS)

Precautions:

• Ensure stable power supply.

• Proper cooling arrangement.

• Use protection circuits.

• Proper grounding and shielding.

• Handle with care during installation and maintenance.
