ABB CR324FXLS Three-pole overload relay

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB CR324FXLS Three‑Pole Overload Relay is a thermal overload protective device designed to protect three‑phase AC motors from overload and stall conditions. It is typically mounted in conjunction with a contactor in motor starter circuits and utilizes bimetallic thermal elements for reliable trip performance.

The relay can be reset manually or by remote/electrical reset if used with auxiliary control circuits and provides auxiliary contact outputs for alarm or interlock signaling.

2. Technical Specifications (Typical)

• Model: CR324FXLS

• Type: Three‑Pole Thermal Overload Relay

Rated Operating Current Range:
‑ 12 … 18 A (adjustable range, typical)

Poles: 3P (Three poles)

Trip Characteristics:
‑ Thermal delay trip
‑ Balanced three‑pole thermal elements

Mounting:
‑ Mounted with a contactor assembly or independent DIN rail/base mount (as needed)

Reset Options:
‑ Manual reset
‑ Remote/electrical reset via auxiliary control circuit

Auxiliary Contact Function:
‑ Normally Closed (NC) trip/alarm contact for remote signaling

Voltage Supply:
‑ Overload relay is thermally driven by the main circuit
‑ Auxiliary contact coils may be powered by 24 V DC / 110–240 V AC/DC depending on configuration

Operating Temperature:
‑ ‑25 °C to +60 °C (no derating)

Mechanical Life:
‑ ≥ 10,000 operations (typical)

Electrical Life:
‑ ≥ 4,000 operations (dependent on load)

Standards/Installation:
‑ DIN rail or integrated contactor mount

Protection Class:
‑ IP20 (standard industrial)

3. Advantages & Features

✔ Accurate overload protection using bimetallic thermal elements
✔ Adjustable current setting for flexible adaptation to motor rated current
✔ Flexible mounting with contactor or independently in control cabinets
✔ Manual and remote reset options for automation integration
✔ Auxiliary alarm contact for signaling to PLC or alarm systems
✔ Industrial reliability and longevity designed for continuous operation

4. Typical Applications

• Three‑phase AC motor overload protection
• Machine tools and automation equipment
• Pumps, fans, compressors, and HVAC motor protection
• Conveyor and material handling systems
• General industrial low‑voltage motor control systems

5. Installation & Operation Notes

• Match current setting to motor rated load but slightly above to avoid nuisance trips
• Ensure correct wiring: Main terminals should carry motor current through thermal elements; auxiliary contacts should be wired per control logic
• Secure mounting with contactor or proper DIN rail base for mechanical integrity
• Consider ambient temperature as high temperatures can accelerate trip timing
• Verify reset logic: Confirm motor fault condition is resolved before reset
