ABB CP502 control panel

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB CP502 Control Panel

Introduction

The ABB CP502 is a Control and Operator Panel designed for the ABB AC 800M controller family. It provides a local human-machine interface (HMI) for displaying system status, alarms, and event information, while also allowing parameter settings and basic control operations.

Typically mounted on cabinet doors or operator stations, the CP502 works seamlessly with ABB PM-series processors, offering operators a reliable and intuitive interaction interface.

Technical Specifications

• Model: CP502

• Type: Control and Operator Panel

• Display: LCD screen with graphical interface

• Keypad: Multifunction keys for parameter navigation and settings

• Communication: RS-232 / RS-485 / Ethernet (depending on configuration)

• Supply Voltage: 24 V DC

• Functions:

  • Display of system status

  • Alarm and event notification

  • Parameter settings and adjustments

  • Local control and diagnostics

• Mounting: Panel mounting / Cabinet front installation

• Operating Conditions:

  • Operating Temperature: 0 ~ +55 ℃

  • Storage Temperature: -20 ~ +70 ℃

  • Humidity: 5% ~ 95% non-condensing

• Compatibility: Fully compatible with ABB AC 800M control system

Features & Benefits

1. Intuitive Operation – LCD screen with function keys for easy interaction.

2. Real-Time Monitoring – Displays system data and alarms.

3. Seamless Integration – Fully compatible with ABB control systems.

4. Industrial-Grade Design – Strong EMI resistance for harsh environments.

5. Flexible Mounting – Suitable for cabinet doors or operator stations.

6. Simplified Maintenance – Local diagnostics reduce downtime.

Applications

• Power Systems – Power plant automation and generator control

• Petrochemical Industry – Process monitoring and control

• Metallurgy & Mining – Production line control systems

• Water & Wastewater – Process automation and monitoring

• Transportation – Electrification and control systems

• General Industrial Automation

Installation & Maintenance Notes

1. Ensure stable 24V DC power supply.

2. Protect from high humidity, dust, and strong EMI.

3. Operate the keypad properly to prevent damage.

4. Regularly check communication cables and connectors.

5. Keep firmware updated for optimal performance.
