ABB CMCP-01 3AUA0000086913 Capacitor Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• 1. Product Overview

  The ABB CMCP-01 (3AUA0000086913) is a DC link capacitor board for ABB ACS800 and ACS880 variable frequency drives.
  It stores energy and filters the rectified DC voltage, reducing ripple and voltage transients while providing a stable DC supply for the inverter IGBT bridge.
  This board is a critical component of the drive power unit and directly affects drive reliability and lifetime.

  ---

  2. Technical Specifications

  Item	Specification
  Model	CMCP-01
  ABB Part No.	3AUA0000086913
  Type	DC Link Capacitor Board
  Compatible Drives	ABB ACS800 / ACS880
  Function	DC energy storage and filtering
  Rated DC Voltage	600–800 V DC (system dependent)
  Capacitor Type	Industrial aluminum electrolytic capacitors
  Connection	Bolt and busbar mounted
  Mounting	Inside the drive power unit
  Cooling	Forced air cooling from the drive
  Operating Temperature	-10 ℃ to +60 ℃
  Protection	IP20
  Design Life	5–10 years at rated conditions

  ---

  3. Key Features and Benefits

  • Stabilizes the DC link voltage

  • Suppresses voltage ripple and transients

  • Long-life industrial capacitors

  • Fully compatible with ABB ACS drives

  • Improves drive and IGBT reliability

  ---

  4. Typical Applications

  • ABB ACS800 / ACS880 drives

  • Industrial motor speed control

  • Fans, pumps and compressors

  • Cranes, conveyors and rolling mills

  • Automation production lines

  • Energy and heavy-duty drive systems

  ---

  5. Installation and Safety Notes

  • High DC voltage present – always allow the capacitors to discharge before handling

  • Never install or remove under power

  • Ensure proper airflow and cooling

  • Observe correct polarity and mounting

  • Inspect periodically for bulging, leakage or overheating

•
•
