Product Overview

ABB CM15/100S0E0/STD Process Indicator
The ABB CM15/100S0E0/STD is a high-precision industrial process indicator used for displaying, monitoring, and alarming analog signals (such as voltage, current, temperature, or pressure) in industrial automation systems. It receives 4–20 mA or 0–10 V signals from sensors or transmitters and displays the measurement values digitally. The compact module is highly reliable, suitable for panel mounting and integration into control systems in various industrial environments.

Technical Specifications

• Model: CM15/100S0E0/STD

• Device Type: Process Indicator

• Input Signal Type: 4–20 mA DC, 0–10 V DC

• Display: Digital LCD with backlight

• Display Range: Configurable according to input signal

• Accuracy: ±0.1% FS

• Alarm Function: Configurable high/low limit alarm output

• Supply Voltage: 24 V DC

• Output Interface: Relay or analog output (optional)

• Operating Temperature: -10℃ to +60℃

• Protection Class: IP65 (front panel)

• Mounting Method: Panel embedded mounting

• Standards: IEC/EN industrial control and safety standards

Advantages and Features

1. High-Precision Display
   Accurately displays analog signals for real-time monitoring.

2. Multi-Function Alarm
   Flexible high/low limit alarm configuration, can connect to external relays or control systems.

3. Industrial-Grade Design
   High protection rating (IP65), resistant to dust, splashes, and harsh environments.

4. Easy Operation
   Simple panel mounting, intuitive parameter settings.

5. Strong Compatibility
   Works with a variety of 4–20 mA / 0–10 V sensors and transmitters, adaptable to various industrial process signals.

Typical Applications

• Industrial automation process monitoring

• PLC/DCS system signal display and alarming

• Level, pressure, and temperature monitoring in chemical, pharmaceutical, and food & beverage industries

• Water treatment and wastewater monitoring

• Power and energy management systems

• Industrial boilers, fans, and pump station signal monitoring

Installation & Usage Notes

1. Power Off Before Installation: Disconnect power before installing or servicing.

2. Correct Wiring: Connect input signals and power according to wiring diagrams to prevent misoperation.

3. Environmental Conditions: Install in dry, ventilated areas, avoiding high humidity, dust, or corrosive gases.

4. Signal Matching: Ensure the input signal type matches module settings to avoid display errors.

5. Regular Maintenance: Check the display module and wiring to ensure long-term stable operation.
