ABB CM-IWS.1S 1SVR730660R0100 Insulation Monitoring Relay

Product Overview

The ABB CM‑IWS.1S is an industrial-grade insulation monitoring relay designed for continuous monitoring of insulation resistance in unearthed (IT) power systems. When the insulation resistance drops below the set threshold, the relay triggers an alarm or control output to ensure safe system operation. Suitable for AC, DC, or mixed power networks.

Technical Specifications

• Model: CM‑IWS.1S

• ABB Part Number: 1SVR730660R0100

• Type: Insulation Monitoring Relay

• Monitored Parameter: Insulation resistance of unearthed (IT) systems

• Supply Voltage: 24–240 V AC/DC

• Measuring Range: 1–100 kΩ

• Output: 1 changeover contact (SPDT, 1 c/o)

• Contact Rating: 250 V AC / 4 A (typical)

• Frequency Range: DC or 15–400 Hz

• Mounting: DIN rail (IEC/EN 60715)

• Terminal Type: Screw terminals

• Operating Temperature: –25 °C … +60 °C

• Storage Temperature: –40 °C … +85 °C

• Dimensions (W×H×D): 22.5 × 85.6 × 103.7 mm

• Protection Degree: Housing IP50 / terminals IP20

• Indicators: LEDs for supply, fault, and relay status

• Weight: Approx. 0.148 kg

• Certifications: IEC 61557 series, UL, CSA

Advantages and Features

1. Wide Supply Voltage Compatibility
   Operates with 24–240 V AC/DC systems.

2. High Sensitivity
   Monitors insulation resistance from 1–100 kΩ, detecting insulation deterioration or faults.

3. Flexible Output Control
   SPDT relay output for alarms, power disconnection, or PLC/DCS integration.

4. Clear LED Indication
   Quick diagnostics with power, fault, and relay status LEDs.

5. Compact DIN Rail Design
   Easy installation in control panels and switchgear.

6. Wide Frequency and Environment Tolerance
   Works in AC, DC, or mixed systems under standard industrial conditions.

Typical Applications

• Insulation monitoring in IT (unearthed) systems

• Industrial power distribution insulation health check

• Preventive maintenance of electrical equipment

• UPS, server rooms, and DC systems monitoring

• Chemical, manufacturing, and automation system insulation alarm

• PLC/DCS system integration and safety protection

Precautions

1. Ensure the system is an unearthed IT system with supply voltage 24–240 V.

2. Mount properly on DIN rail and secure screw terminals with good grounding.

3. Set threshold values according to system insulation requirements and test before operation.

4. Avoid extreme temperature, humidity, and corrosive environments.

5. Periodically check relay outputs and LED indicators for accurate monitoring.

The structure and details of the product：
